220vac to 24vdc waterproof led lighting power supply LED driver IP67 IP66 36w
- Category: >>>
- Supplier: Zhengzhou C-Power Electronics Firm
Share on (60681995360):
Product Overview
Description
Product Description
Output Voltage: DC 12V,DC 24V
Material: Aluminum
IP Grade: IP67 Waterproof
Working Temperature:-45 to 49degree
Output | DC Voltage | 12V | 24V |
Rated Current | 3A | 1.5A | |
Current Range | 0~3A | 0~1.5A | |
Rated Power | 36W | 36W | |
Ripple&Noise | 120Vp-p | 150Vp-p | |
Set up,Rise time | 500ms, 20ms / 230VAC | ||
Input | Voltage Range | 110~265VAC 47~62Hz | |
Efficiency | 84% | 85% | |
Ac Current | 0.5A/230VAC | ||
Leakage Current | 0.25mA / 240VAC | ||
Inrush Current | Cold Start <40A at 230VAC | ||
Protection | Over Current | 110~140% rated output power | |
Protection Type | Hiccup mode, recovers automatically after fault condition is removed | ||
Over Voltage | Hiccup mode, recovers automatically after fault condition is removed | ||
Environment | Working Temp&Humidity | -30-60°C 20-90% RH | |
Storage Temp&Humidity | -40-80°C 10-90%RH | ||
Safety&EMC | Safety Standards | IP67 Approved ,Design Refer to: EN60950 | |
Withstand Voltage | I/P-O/P:3KVAC I/P-FG:2KVAC O/P-FG:0.5KVAC | ||
Isolation Resistance | I/P-O/P:>100M Ohms / 500VDC | ||
EMC Emission | Compliance to EN55022 (CISPR22) Class B,EN61000-3-2 Class A, EN61000-3-3 | ||
EMC Immunity | Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, Criteria A
| ||
Special Note
This Power Supply Unit "DOES NOT" come with installation instruction, wiring cable,on/off switch, or screws.
Professional Installation of qualified electrician is highly recommended.
Note:
1.This is a DC12V or DC 24V (your choose)Power Supply Unit for professional use on LED lightning, Security Surveillance System, CCTV Security Camera, IP Camera, and etc.
2.Safety design with shortage protection, overload protection and auto voltage switching.
3.Regulated voltage & current output. This is a perfect choice to use as a LED Driver for all type of LED lighting 3.without flickering light & ensue the life span of your LED.
4.Full range of current output is possible for LED lighting with dimmable function.
About Calculate Method:
If Your LED Strip 60LEDs/m, and each LED 0.2W, then calculate max led Strip Length: 0.2W/LED × 60LEDs/m=12W/m, 24W(this listing)÷12W/m=2m,
So, Support the LED Strip(60LEDs/m, 0.2W/LED) Length (Max)=2m
Special Note:
This Power Supply Unit "DOES NOT" come with installation instruction, on/off switch, or screws.
Professional Installation of qualified electrician is highly recommended.
