AUS india Plug adapter for 5V 2A adaptor power adapter

Product Overview

Description

  AUS india Plug adapter for 5V 2A adapter





AUS india Plug adapter for 5V 2A adapter

1.100% full-load burning test

2.Over current, short-circuit protection



1.Oprating temperature, 0~40°C

2.Oprating humidity , 10~90%RH

3.Storage temperature, -20~+80°C

4.Storage humidity , 5~90%RH

5.Leakage current , 0.25mA max

6.Withstanding voltage, 3000Vac 1 minute 10mA max

7.Burn-in 100% full load,40±5°C,4Hrs min

8.MTBF meet MIL-HDBK-217F over 50k hours, full load 25°C

9.Insulation resistance , 500Vdc 100MΩ min between AC plug and DC plug and case.





Protection:

Over current protection

Over voltage protection

Short circuit protection





Input Voltage	100~240V
Output Voltage	5~36V
Output Current	0.5A~3A
Frequency	50/60hz
Max output Power	18W





Suggested application: Digital Camera, Notebook adapter, laptop adapter ,ADSL AP, Wireless Lan Station, LCD Monitor, Hard Disk, Communication Terminals, Any Portable Device or Machine ,etc.
