China Supply Plate Uht Sterilization Equipment For Aseptic Beverage Producing Line
- Category: >>>
- Supplier: Weishu Machinery Technology (Shanghai) Co. Ltd.
Share on (60682319941):
Product Overview
Description
Product Description
plate small uht sterilization equipment for
aseptic beverage producing line
Product Application
The sterilizer can take hot process on the liquid foods and beverage.
Model | WSBS-UHT-1 | WSBS-UHT-2 | WSBS-UHT-3 | WSBS-UHT-4 | WSBS-UHT-5 |
Production capacity(T/H) | 1 | 2 | 3 | 4 | 5 |
Heat exchanging area(m2) | 16 | 26 | 38 | 46 | 56 |
Materal inlet temperature(ºC ) | 5 | 5 | 5 | 5 | 5 |
Materal outlet temperature(ºC) | 5 | 5 | 5 | 5 | 5 |
Sterilizing temperature(ºC) | 137 | 137 | 137 | 137 | 137 |
137Warmkeeping time(S) | 4 | 4 | 4 | 4 | 4 |
Ice water temperature(ºC) | 1 | 1 | 1 | 1 | 1 |
Ice water cos(T/h) | 3 | 4 | 6 | 8 | 12 |
Jiont size(mm) | φ 25 | φ 38 | φ 38 | φ 51 | φ 51 |
Weight(kg) | 980 | 1080 | 1160 | 1350 | 1680 |
Size(mm) | 1500*1500*2000 | 1900*1800*2200 | 1900*1800*2200 | 1900*1800*2200 | 2600*2200*2500 |
Power(kw) | 3 | 4 | 5 | 6 | 6 |
Main Features
The machine adopts UHT Processing method,makes the liquid dairy beverage and juice etc strictly sterilized,then into aseptic package,with the sterilization temperatture 137 degree,warm keeping time 3-5s. so to keep the original nutrition,color and flavour of the beverage and diry, this machine os of the advantage of high heat recycle,compact and fine structure,and temperature control.Outputting material temperature , and cool package.Capacity 1-10T controling way semi-automatic,full automatic (PLC controling, touc screen) .
UHT Plate type Sterilizer is PLC controlled,with optional capacity from 1t/hr to 15t/hr.The system work in aseptic section and normal section, for the technical require-ments of filling at low temperature,normal temperature and high temperature. The seven-section heat exchanger ensures minimum consumption of energy,and perfect design of CIP and SIP satisfies the demand of cleaning and sterilization.Ultra-high temperature water is employed as the media for the heating of materials and temperature adjustment of filling exit,featuring high accuracy.
Packing & Delivery
H.S. Code | 8419200000 |
Packaging Details | The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request. |
Delivery Details | 30-60 days after the deposit |
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* View our Factory.
After-Sales Service
* Training how to install the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Related Products
Tube UHT Sterilizer
Bottle Tilting Sterilizer
Spray Sterilizer
Pure Water Producing Machine
Bottle Unscrambler
Washing-Filling-Capping 3-In-1 Machine
Storage Tank
Seed Tank
Cooling And Heating Cylinder Tank
Emulsifying Tank
Vacuum Degasser
CIP System
Our Company
Our company is a scientific research, production and service in the enterprise, has the domestic first-class beverage manufacturing equipment, a professional engineering and technical personnel to provide customers with the production technology and formula of products, the company introduced the most advanced foreign food machinery manufacturing technology and create a fully automated CIP advanced cleaning system, automatic control pressure and vacuum filling equipment through their own digestion, plate type and tube type UHT sterilization equipment and aseptic filling temperature in a full set of equipment, has become the backbone of the national food machinery industry, the company always adhere to the tenet of serving the users, pay attention to the research and development of new technology, comprehensive development with high capacity and perfect quality assurance system, products sold throughout the country and Southeast Asia, the Middle East, praised by the majority of users.
Our main products are: (1) pure water processing complete set of production equipment (2) full set of dairy processing system (3), UHT tube type sterilization unit (4) and spray water bath sterilization tunnel (5) PET three and a pressure negative pressure filling machine (6) glass bottles and cans filling and sealing machine (7) dairy production line, the formation temperature of aseptic filling system in PET fruit juice tea beverage production line, biological engineering and enzyme production line of three series.
