Business card cutter/card cutting machine a4 manufacturer
US $100.00-$120.00
FQJ 1300B 250m/min speed medium paper slitting machine
- Category: Paper Processing Machinery >>>
- Supplier: Wenzhou Winrich Machinery Co. Ltd.
Share on (60682483572):
Product Overview
Description
Product Description
YILIAN New design high speed paper slitting machine
FQJ-1300B-2100B type microcomputer high speed paper cutting machine is suitable for cutting edge and cutting of large
coiled material. Such as printing and packaging plastic membrane type, paper, cloth and all kinds of paper plastic composite
materials such as Lin Mozhi, coated paper, synthetic leather, such as.
1.the use of circular knife cutting, division of high precision, easy to operate,the cutter can be arbitrarily adjusted;
2.the use of A, B axis independent winding,loading and unloading operation is convenient;
3.fold and shaft adopts inflatable shaft,automatic tension control,orderly and compact rewinding of finished products;
4.put the material frame using air pressure automatic lifting function;
5.waste edge automatic discharge device;
6.this machine adopts frequency conversion speed regulation. Microcomputer automatic control, selection of imported Yuan
Electrical corrective device, automatic meter alarm parking, tension digital display advanced features.
Technical parameter:
|
Model |
FQJ-1300B |
FQJ-1600B |
FQJ-1800B |
|
Dia. of unwinder |
1400mm |
1400mm |
1400mm |
|
Width of slitting |
1200mm |
1500mm |
1700mm |
|
Dia.of rewinder |
1000mm |
1000mm |
1000mm |
|
Mini slit width |
30mm |
30mm |
30mm |
|
Speed |
10-150m/min |
10-150m/min |
10-150m/min |
|
Slitting accuracy |
±0.3mm |
±0.3mm |
±0.3mm |
|
power |
11kw |
15kw |
18kw |
|
electric |
380V/50Hz Tri-phase |
380V/50Hz Tri-phase |
380V/50Hz Tri-phase |
|
requirement of air pressure source |
5.5kg/cm2×0.5m3/min |
5.5kg/cm2×0.5m3/min |
7.5kg/cm2×0.5m3/min |
|
weigh |
4500kg |
5500kg |
6500kgs |
|
overall dimension |
4300*3600*1800mm |
4500*3600*1800mm |
4800*3600*1800mm |
