Electric Tow Tractor|Electric Tow Tractor|Electric Tow Tractor|Electric Tow Tractor|Electric Tow Tractor|Electric Tow Tractor|Electric Tow Tractor|Electric Tow Tractor
1. Because of CURTIS electronic control,multiple automatic protection system controller.
2. EPS swerve can reduce 20% of the energy consumption.
3. Forklift temporary parking ramp adopt both electronically controlled and the foot brake to get a double insurance.
Name
Electric Tow Tractor
Operation type
Seated Type
Model No.
Unit
EPQ40A
EPQ60A
Power type
Electric
Wheel type
Rubber
Maximum traction weight
KG
4000
6000
Max. traction
N
2300
2300
The instantaneous maximum traction
N
4000N
The vehicle height
H2(mm)
1420
1420
Overall length
L(mm)
2010
2010
Overall width
S(mm)
985
985
Max. Travel speed
Km/h
16/10
16/10
Wheelbase
mm
1340
1340
Turning radius
Wa(mm)
1523
1523
Battery weight
KG
550
550
Steering type
EPS
EPS
Parking brake type
Manual operation/Pedal type
Body weight
KG
1100
1200
Front wheel
mm
Ø295*96
Ø295*96
Rear wheel
mm
Ø415*112
Ø415*112
Battery capacity
V/Ah
48/240
48/280
Charger-intelligent
V/Ah
48/30
48/40
Drive motor
Kw
4
4
Packaging & Shipping
Packaging Details:
Export standard package; Full set documents including spare parts list, operate maintenance manual and engine operate manual; One set of inspeciton certificate issued by manufacturer; One set of common use tools; All above mentioned will be put in tool box for Electric Tow Tractor.
Delivery Detail:
Whole machine by sea and spare parts by delivery or according to your demand,Shipped in 25 days after payment
Company Information
About our company
1. Anhui Yufeng Equipment Co.,Ltd. is a high-tech enterprise professionally specialized in R&D, production, sales, service of electric storage and intelligent industrial system.
2. It is located in Feixi Huagang industrial park in Anhui, with advanced forklift manufactory technology, processing equipment and perfect product testing center. Our company is the China Automobile Industry Association member unit.
3. We won the honorary title such as “Outstanding Enterprise of Quality Management, Credibility and Service AAA level”, "National Enterprise of Good Creditworthiness", "National Quality Management Advanced Enterprise" and "Anhui Famous Brand" etc.
4. The company has already passed the safety production standardization and the quality authentication of ISO9001 and European Union CE certification, fit-out national patent certificate.
5. Our main storage equipment are electric truck,stacking car,reach forklift trucks,towing vehicle, order picker, AGV pilotless truck, counter balanced weight forklift and so on.They are widely used in various places of modern logistics.
FAQ
1. How long it will take to deliver the products after I pay for it?
Above delivery time is 26 days.
2. What is the payment term?
Our Payment: T/T, L/C, etc.
3. How long is the warranty period any forklift, pallet truck, stacker, tow tractor, order picker etc?
Our equipment quality warranty is 1 year or 1000 hours which comes first.
4. What kinds of engine do you have and any gurantee?
Electric motor, CURTIS controller. Absolutely high quality.
5. How many colors of forklift you can supply?
Green, Orange, Yellow, Red. Or As Per Your Request.
6,What is the forklift standard configuration and spare parts?
Wide vision mast,standard fork,standard seat, direction switch,backrest,reversing lights,reversing buzzer,back-up mirror,light switch,light armor rack,klaxon,two pieces of multi-way valve,electric control,rear combination lamp,overhead guard,rain cover,urable tyre,lasso-parking brake,lifting and tilt joystick,rate-limiting valve of lifting,draebar pin,lighting,adjustable steering wheel,lilt line self-lock valve,full hydraulic power steering,handle,tool box,combination instrument,hydraulic return filter,hydraulic oil suction filter,hydraulic vernier,switch,brake,turning indicator.
Our Services
Professional R&D team provide consumers the most comprehensive and reasonable technology integrated solutions.
Customized order can be met upon drawing and sample confirmed.
One-to-one 48 hours full-time service to solve customers’ problem.
