underground electrical armoured cable 4 core power cable 25mm 35mm 50mm 70mm 95mm 120mm 185mm 240mm 300mm power cable
- Category: >>>
- Supplier: Yiteng Cable Technology Hebei Co. Ltd.
Share on (60684220588):
Product Overview
Description
underground electrical armoured cable 4 core power cable 25mm 35mm 50mm 70mm 95mm 120mm 185mm 240mm 300mm power cable
Product Description
1. Uo/U: 450/750V, 0.6/1KV, 1.8/3KV, 3.6/6KV, 6/10KV, 8.7/15KV, 12/20KV, 18/30KV, 21/35KV, 26/35KV
2. Standard applied: IEC, GB, BS, VDE, AS/NZS, UL or as per requirement
3. Working temperature: 70~125 °C
4. Conductor: solid or stranded pure annealed copper or aluminum
5. Insulation: XLPE or PVC or PE or LSZH
6. Cores: 1~5 cores, 3+1 cores, 3+2 cores, 4+1 cores for low voltage, 1 core or 3 cores for MV power cable
7. Cross section area: 1.0~630 sqmm for single core, 1.0~300 sqmm for multicores
8. Armoure: armore type is optional, SWA (steel wire armored) or STA (steel tape armored) for multicores, AWA (aluminum wire armored) or ATA (aluminum tape armored) for single core
9. Sheath: PVC or PE or Low smoking and halogen free compounding, etc.
10. Color: black or as per requirement
11. Flame retardant or Fire resistance or Low smoking and halogen free or other properties can be available
12. Wooden drum package or as per request
13. Certificates: ISO9001, ISO14001, OHSMS18001, CE, CB, CCC, SAA, etc
14. OEM can be available
15. BDK cables have very good sales over the world, enjoying a very good reputation based on top quality and most competitive price and 5-star service.
| Type | Name
| Application | |
Cu Conductor | Al Conductor | ||
YJV YJY | YJLV YJLV | XLPE Insulated,PVC or PE S heathed Power Cable | For laying in door,tunnel,channel and underground.Unable to bear external mechanical force,but bear the traction force during laid. |
YJV22 YJV23 | YJLV22 YJLV23 | XLPE Insulated,Steel Tape Armoured,PVC or PE Sheathed Power Cable | For laying in tunels in door,tunnel,channel and underground.Able to bear external mechanical force,but unable to bear large pulling force. |
YJV32 YJV33 | YJLV32 YJLV33 | XLPE Insulated,Fine Steel Wire Armoured,PVC or PE Sheathed Power Cable | For laying in shaft with large difference of level.Able to bear external mechanical force,and moderable pulling force. |
YJV42 YJV43 | YJLV42 YJLV43 | XLPE Insulate,Thick Steel Wire Armoured,PVC or PE Sheathed Power Cable | Able to bear positive pressure and pulling force |
| 1st class | 0.6/1 | 1.8/3 | 3.6/6 | 6/10 | 8.7/15 | 12/20 | 18/30 | 21/35 | |||
2nd class | 1/1 | 3/3 | 6/6 | 8.7/10 | 12/15 | 18/20 | - | 26/35 | ||||
1 Core | Section area(mm2) | 1.5-800 | 25-800 | 25-800 | 25-800 | 35-800 | 50-800 | 50-800 | 50-800 | |||
2 Core | Section Area(mm2) | 1.5-185 | / | / | / | / | / | / | / | |||
3 Core | Section area(mm2) | 1.5-400 | 25-400 | 25-400 | 25-400 | 35-400 | 50-400 | 50-400 | 50-400 | |||
4 Core | Section Area(mm2) | 2.5-400 | 25-400 | / | / | / | / | / | / | |||
5 Core | Section area(mm2) | 2.5-400 | 25-400 | / | / | / | / | / | / |
If you want to contact the supplier,you can click here>>>>>>sent enquiry
Constructions:
Our Main Product
 |  |  |
 | ||
 |  | |
Company Information
Customers visiting our factory:
Certificates:
Our Services
Yiteng Cable will be always at your service
OEM and ODM service
sample free leadtime 2-3 days
bulk goods leadtime 7-10 days after advanced payment
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods
are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A:T/T,L/C,D/P,D/A
For the first business: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before
shippment.For the second deal , and if the clients are reliable and with good reputations , Open Account is acceptable,
but the buyer should pay the interest for the capital of the contract titled goods at the rate of 0.05% per day.
Q:What's the MOQ?
A: According to different types often 500 meters-1000meters
If you have another question, pls feel free to contact us.
