Professional supplier of Auto Focus Real Time Focus hd ccd camera

Product Overview

Description

Professional supplier of Auto Focus Real Time Focus hd ccd camera

Observation position is always in real time focus, and Manual focus is not required. Providing 1080P HD image.

High resolution 1080P

High speed 60FPS

Ultra clear HDR

Model Number	HDMI-200ZD
Sensor Type	CMOS Colour
Effective Pixels	2 Million
Pixel Size	1/2.8” (5.38x3.02mm)
Display Frame Rate	1080P60Hz/1080P50Hz
Scanning Mode	Progressive Scanning
Shutter Speed	1/50s(1/60s) ~ 1/10000s
Signal-to-noise Ratio	>50DB
White Balance	Manual/Auto/Onekey White Balance
Exposure Mode	Auto/Manual
Line Control Function	Yes
Lens Interface	C/CS
Power Supply DC	DC5V
Output Mode	HDMI
Working Temperature	0~50 Centigrade
Size	66mm x 66mm x 80mm
Weight	420g



Optical Magnification	Video Magnification	Focus Clear Range
1x	88x	13.0mm
2x	177x	3.5mm
3x	265x	1.0mm
4x	354x	0.8mm
5x	442x	0.5mm
The video magnification is the magnification when 21.5 inch display is working. Because of different optical lenses, the focus clear range will be a slight different.















Beijing PDV Instrument Co., Ltd is a collection of optics, precision machinery, automatic control technology independent high-tech research and development enterprises. Since 2005, we have been serving the scientific research institutes and universities. We have developed the hardware and software system (optical path construction, software development, mechanical circuit design, etc.) according to the needs of customers. Through long-term unremitting efforts, the process of building the system to control the optical path and excellent service to customers, we’ve grown into a well-known manufacturer among scientific research, colleges and universities, machinery automation and many other areas.
