Steam rubber vulcanizing machine/Automatic electric vulcanizer

Product Overview

Description





Steam rubber vulcanizing machine/Automatic electric vulcanizer



INDUSTRY AUTOCLAVE CHARACTERS:

1.Automatic MITSUBISHI control system with touch screen view panel, less workers ,

2.Insulation and steam heating automatically make low energy consumption & best power efficiency

3.Door open&close security guaranteed by chain lock system,easy operation and maintenance .

4.Detector of probes automatic control temperature,pressure and time .

5.Payment and Transportation could negotiated while business discussion .

6.Meet ASME or international standard.







FEATURES:

1. Curing the autoclave with high temperature and pressure.

2. Once the temperature and pressure be set, all operation going automatically.

3. Shell material Q345R with 50 mm aircraft grade insulation.

4. Vulcanization performance with electric heating method.

5. Air circulation with motor fans and circulation channel.

6. Evenly temperature distribution with high temperature works on the rubber terms.

7. Each group of heating tube controlled independent.

8. Voltage and frequency 380V/50Hz, or follow customer request.













12m length autoclave for rubber high temperature



Technology Parameters:

Item	Details
Inner diameter	1500mm
Length	5000mm
Capacity	8.83 m³
Design pressure	0.6Mpa
Working pressure	0.6Mpa
Design temperature	170℃
Working temperature	160℃
Material	Q345R
Body thickness	14 mm
Control	Semi-automatic
Door open	Automatic hydraumatic control
