1.Material: stainless steel 304/316l, and choose the best accessories suppliers. 2.Machine size: custom made 3.Machine Volume can be customized 4.Condition: Brand-new, 100% manufactured from Lianchuang factory.
5.Package:plastic cover, packed in shockproof plywood boxes,or as request 6.Features: (1) Easy to handle/operating with the PLC control system, and easy to clean/maintance. (2) Different stirring paddles to choose, Sigma/Z-shape/Fishnail/and cutter-blades (3) Dicharge ways: Tank-tilting, pupm-extruding, bottom manual/hydraulic open and ball-valve. (4) Speed control: PLC system with inverter to control the paddle rotating speed as request. (5) Motor and Reducer: Equiped with the known brand Siemens motor and Guomao Reducer. (6) Heating/Cooling/vacuum and Heavy duty system available as request.
(7) Function: Specially for shearing,squeezing,crushing,mixing and kneading powder/liquid viscous material.
Type
Volume Capacity (L)
Working Capacity(L)
Motor Power(KW)
Discharging methods
Heating method
NHJ-1L
1
0.6
0.75
Tank tilting,Ball valve,Screw extruding
steam, eletric heating oil, hot water
NHJ-2L
2
1.2
0.75
NHJ-5L
5
3.0
1.5
NHJ-10L
10
6.0
2.2
NHJ-20L
20
12.0
3.0
NHJ-50L
50
30.0
3-5
NHJ-100L
100
60.0
5-7.5
NHJ-200L
200
120.0
7.5-11
NHJ-300L
300
180.0
11-15
NHJ-500L
500
300.0
15-22
NHJ-800L
800
480.0
22-40
NHJ-1000L
1000
600.0
40-45
NHJ-1500L
1500
900.0
30-55
NHJ-2000L
2200
1300.0
45-75
NHJ-3000L
3000
1800.0
55-90
NHJ-5000L
5000
3000.0
90-160
Company Information
Rugao City Lianchuang Kneader Machinery Co., Ltd, an enterprise integrating design, production, sale and service of kneader& kneading machines as well as in researching and developing kneading machines. Based on the advanced technology, craft, equipments, and variety, we have rich experience in manufacturing kneading machines, mechanical mixer and the raw material production line as the various requests of customers. Our products are widely applied to petrochemical industry, CMC,DMC, rubber, plastics, printing ink graphite, PU color film, electric powder, masterbatch,compound stabilizer, pigment, glass glue, pharmaceutical/medicine, food, cellulose, pigment dyestuffs, silicone sealant, high polymer material and plastic-based etc with the capacities range from 1 L to 8000L.
