Manual electrostatic lab powder coating spray gun with powder coating equipment
- Category: >>>
- Supplier: Weifang Galin Powder Coating Equipment Co. Ltd.
Share on (60686816736):
Product Overview
Description
Product Description
Manual electrostatic lab powder coating spray gun with powder coating equipment
Electrical data
GalinFlex 2C |
|
Nominal input voltage | 100V240VAC |
Frequency | 50-60Hz |
Connected load (without vibrator) | 40 VA |
Nominal output voltage (to the gun) | eff.10 V |
Nominal output current (to the gun) | max. 1.2 A |
Connection for rinsing function (valve) | 24 VDC max. 3 W |
Temperature range | 0°C - +40°(+32°F - +104°F) |
Max. surface temperature | 100 °C (+212 °F) |
Approvals | II 3 D IP54 120 °C |
Pneumatical data
GalinFlex 2C |
|
MAX.input pressure | 10bar |
MIN.input pressure | 6bar |
Input pressure (Dynamic based on pressure regulator setting) | 5.5 bar / 80 psi |
Max.water vapor content of the compressed air | 1.3g/Nm³ |
Max.oil vapor content of the compressed air | 0.1mg/Nm³ |
Max.compressed air consumption | 11Nm³/h |
Dimensions
GalinFlex 2C |
|
Width | 444mm |
Depth | 310m |
Height | 428mm |
Weight | 12kg |
Processible powders
Plastic powder | yes |
Metallic powder | yes |
Enamel powder | no |
Packaging & Shipping
Packing:Carton
Shipping: 4-10 days of payment
Our Services
WeiFang Galin Powder Coating Equipment CO.,LTD specialized in electrostatic powder coating equipment .
We can supply the best quality and sevice .
Technoligy consult Service
One year warranty Service
After market and exhibtion Service
OEM Service
Company Information
Weifang Galin Powder Coating Equipment CO.,LTD which located in Shandong district,specializes in manufacturing the coating equipment .We are a typical Chinese supplier and specialized in the research, development and production of the powder coating system and liquid painting system. Our products includes booth, hopper,powder coating machine/unit,electrostatic spray gun ,panel controller,HV module,PCB board, injector/pump ,powder hose,filter and other parts and so on.In addition,we can make all kinds of high voltage module,like Gema,Wagner,Nordson etc.
We not only supply the high-quality coating equipment,but also the best service.
If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us.
