| Parameter/model | X(S)N-3 | X(S)N-10 | X(S)N-20 | X(S)N-35 | X(S)N-55 | X(S)N-75 | X(S)N-110 | X(S)N-150 | X(S)N-200 |
| Total volume (L) | 8 | 25 | 45 | 80 | 125 | 175 | 250 | 325 | 440 |
| Working volume (L) | 3 | 10 | 20 | 35 | 55 | 75 | 110 | 150 | 200 |
| Driving motor power (KW) | 7.5 | 18.5 | 37 | 55 | 75 | 110 | 185 | 220 | 280 |
| Tilting motor power (KW) | 0.55 | 1.5 | 1.5 | 2.2 | 2.2 | 4 | 7.5 | 15 | 7.5 |
| Tilting angle | 140 | 140 | 140 | 140 | 140 | 140 | 140 | 140 | 140 |
| Rotor speed (RPM) | 32/25 | 32/25 | 32/26.5 | 32/24.5 | 32/26 | 32/26 | 30/24.5 | 30/24.5 | 30/24.5 |
| Pressure of compressed air (MPA) | 0.7-0.9 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 | 0.6-0.8 |
| Capacity of compressed air (m³/min) | ≥0.3 | ≥0. 5 | ≥0.7 | ≥0.9 | ≥1.0 | ≥1.3 | ≥1.6 | ≥2.0 | ≥2.0 |
| Pressure of cooling water (Mpa) | 0.2-0.4 | 0.2-0.4 | 0.2-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 | 0.3-0.4 |
| weight (kg) | 1038 | 3000 | 4437 | 6500 | 7850 | 10230 | 14200 | 19500 | 22500 |
