Hospital Ultra Pure Distilled Water Machine With Competitive Price TEST
- Category: >>>
- Supplier: Sichuan Zhuoyue Water Treatment Equipment Co. Ltd.
Share on (60687866462):
Product Overview
Description
Products Description
ZYTEST--Medical DI Water Machine
ZYTEST Deionized Water System for Hospital Test is usually used for rountine chemical laboratory analysis instruments especially
biochemical analyzer. The equipement with simple and generous appearance can easily produce water grade II (0.1-1 us/cm ultra-pure
water) and water grade III (2-10 us/cm pure water for glass ware washing) which meets standard ASTM, CAP, NCCLS, GB and
T6682-2008.\t
ZYTEST Deionized Water System for Hospital Test is usually used for rountine chemical laboratory analysis instruments especially
biochemical analyzer. The equipement with simple and generous appearance can easily produce water grade II (0.1-1 us/cm ultra-pure
water) and water grade III (2-10 us/cm pure water for glass ware washing) which meets standard ASTM, CAP, NCCLS, GB and
T6682-2008.\t
Model list
Configurati on grade | l | ll | ll | lV | |||||
Benchtop (L/H) | ZYTEST-l-10/20L | ZYM-ll-10/20L | ZYTEST-ll-10/20L | ZYM-lV-10/20L | |||||
Floor style (L/H) | ZYTEST-l-20/40/60/80/100/120/150L | ZYM-ll20/40/60/100L | ZYTEST-ll-20/40/60/80/100/120/150L | ZYM-lV-20/40/60/100L | |||||
Inlet water source | city tap water(TDS<200ppm),water pressure2.0-4.0kg/cm2 , water 10-30℃ | ||||||||
Capacity | 10/20/40/60/80/100/120/150L | ||||||||
DI product water quality (uS/cm) | Conductivity ＜ 0.1～1 uS/cm (on-line monitoring), converted resistivity ≥ 1～10 MΩ.cm Micro particulate matter (≥0.2um) < 1/ml, bacterial removal rate ≥99% | ||||||||
UP quality （MΩ.cm） | Resistivity 18.25MΩ.cm (online monitoring) Heavy metal ions＜0.1ppb Total Organic Carbon (TOC)＜20ppb Microparticles (≥0.2um) | ||||||||
Configuration | Single display table + DI column | MF (Terminal filter) | Dual display + ultra-purification system | MF+UV+UF | |||||
Product size(mm) | 510*380*570mm (Benchtop) | 530*420*1120mm(Floor style) | |||||||
Product weight(kg) | 30-35kg(Benchtop) | 40-65kg(Floor style) | |||||||
Power(W) | 30W-50W(Benchtop) | 50W-100W(Floor style) | |||||||
Application | Hitachi, Olympus, Beckman, Toshiba, Roche, Abbott, Bayer, Mindray, Dire, Deling, Liba, Kehua, Senlong, Neusoft, Redu, Innovax and other imported and domestic brands of biochemical instrument water ; 1. Routine biochemical analysis and testing in the laboratory; 2. Routine quantitative analysis such as physical and chemical testing; 3. Water for immunohistochemical analysis of pathology department | Hitachi, Olympus, Beckman, Toshiba, Roche, Abbott, Bayer, Mindray, Dire, Deling, Liba, Kehua, Senlong, Neusoft, Redu, Innovax and 1. Atomic absorption (AA); other imported and domestic brands of biochemical instrument water ; 2. Atomic Emission (AES); 3. High performance liquid chromatography (HPLC); 4. High-performance liquid chromatography (HPLC) and other instruments with high analytical precision to analyze water; | |||||||
A. 10L/20L (Benchtop) comes standard with a 3.2G pressure pure water tank; B. 20L/40L/60L (Floor style) comes standard with a 40L pure water tank; C. 80L/100L/120L/150L (Floor style) comes standard with a 100L pure water tank; Note: The size of the water tank can be selected according to the user's situation. | |||||||||
Special configuration | Power: 100～150W | Weight: 90～150Kg | |||||||
Host size 1: D700*W520*H1470 mm | |||||||||
Product features
The Features of Medical Distilled Water Equipment
· The pre-treatment system can filtrate particles, ions, manganese, residual chlorine,Mg2+, Ca2+, microorganism and odor;
· Automatic flushing system can extend the working life of consumables;
· The dealinization rate of RO membrane can arrive at 99%;
· Excessive discharge of substandard water ensures ultrapure water's quality;
· Automatic alarm when the UP water is not up to standard;
· Function: self test (power on), automatic alarm (water shortage), automatic stop (water full), protection (low pressure);
· Resistivity&conductivity meter monitor online;
· Equipe pressure water tank and PE water tank to meet pressure or self-priming type biochemical analyzer.
· The pre-treatment system can filtrate particles, ions, manganese, residual chlorine,Mg2+, Ca2+, microorganism and odor;
· Automatic flushing system can extend the working life of consumables;
· The dealinization rate of RO membrane can arrive at 99%;
· Excessive discharge of substandard water ensures ultrapure water's quality;
· Automatic alarm when the UP water is not up to standard;
· Function: self test (power on), automatic alarm (water shortage), automatic stop (water full), protection (low pressure);
· Resistivity&conductivity meter monitor online;
· Equipe pressure water tank and PE water tank to meet pressure or self-priming type biochemical analyzer.
The process flow
The technology process is divided into source water pretreatment system,reverse osmosis system and ultra-pure system.
1. Source water pretreatment system: PP fiber filter + AC filter + Softener
2. Reverse osmosis system: It has high removal rate more than 99% for high valent ions, colloids, bacteria and organic matter
(including endotoxin) with molecular weight greater than 300Dalton.
3. Ultra pure system: Ion exchange resin using H + exchange cation out the water in the filter ,using OH- exchange anions out the
water , the replaced H + and OH- combined to produce H2O, ultra-purified column filling the United States Dow UPW-450 Ultra-pure
water for nuclear grade resin, the water resistance of up to 18.25 MΩ.cm.
1. Source water pretreatment system: PP fiber filter + AC filter + Softener
2. Reverse osmosis system: It has high removal rate more than 99% for high valent ions, colloids, bacteria and organic matter
(including endotoxin) with molecular weight greater than 300Dalton.
3. Ultra pure system: Ion exchange resin using H + exchange cation out the water in the filter ,using OH- exchange anions out the
water , the replaced H + and OH- combined to produce H2O, ultra-purified column filling the United States Dow UPW-450 Ultra-pure
water for nuclear grade resin, the water resistance of up to 18.25 MΩ.cm.
Product exhibition
Compang information
Sichuan Zhuoyue Water Treatment Equipment Co., Ltd. was established in 2009. It is a comprehensive water treatment manufacturer integrating R&D, production, sales and after-sales. It specializes in R&D and production of laboratory ultrapure water systems, medical pure water systems, and pharmacopoeia purified water systems. , industrial ultra-pure water system, commercial pure water system, waste water treatment system, membrane separation system and related water treatment system. At present, the company has a 4000M2 modern production base and marketing service center in Chengdu, Sichuan, and has established perfect after-sales service network.
Product packaging
Why Choose Us
Why choose us :
1. Professional manufacturer : More than 10 years experience in prodcuing pure water treatment system .
2. Strict time control : Ensure delivery time.
3. Factory strength: The factory area is more than 2000m3, more than 100 workers.
4. After-sales service : 24 Hours online for service.
5. Customized is available. Sample order is available.
2. Strict time control : Ensure delivery time.
3. Factory strength: The factory area is more than 2000m3, more than 100 workers.
4. After-sales service : 24 Hours online for service.
5. Customized is available. Sample order is available.
