8A 12V Lithium battery mppt boost solar charge controller with PIR motion sensor
- Category: >>>
- Supplier: Qingdao Skywise Technology Co. Ltd.
Share on (60688241795):
Product Overview
Description
8A 12V MPPT solar street light charge controller with PIR motion sensor Lithium battery
MPPT0875-DCLiR | ||
Battery Parameters | Max charging current | 8A |
Mppt charging voltage | ||
Charging voltage target | 10.0-17.0V(Programma ble) | |
Charging voltage recovery | 9.2-16.BV(Programmable) | |
Low voltage disconnect | 9.0-15.0V(Programmable) | |
Low voltage reconnect | 9.6-16.0 (Programmable) | |
Battery type | Lithium | |
Panel Parameters | Max solar voltage | 60v |
Max input power | 100W-120W | |
MPPT tracking range | ( Vb+1.0V) -Voc*0.9 * | |
Day/Night threshold | 3.0-20.0V (Programmable) | |
Day/Night delay time | 0-30min(Program ma ble) | |
Load Parameters | Output power | 1-50w |
Output voltage | (Vb+2v)-45v | |
Output current | 0.15-3.0A(Programmable) | |
Min current | 30mA(Dimming) | |
Current precision | ±2% | |
Dimming | 0-100%(Program mable) | |
Voltage of start dimming | 10.0 - Charging voltage target(Programmable) | |
Dimming percentage | 1-20%(Programmable) | |
Induction delay off time | 10-1 SOs(Programmable) | |
Dimming when no people | 0-100%(Prog ramma ble) | |
System Parameters | Max tracking efficiency | >99.9% |
Max charge conversion | 96% | |
Protection degree | IP67 |
