High Potential sacrificial anode Mg Alloy ASTM B843 M1C Casting Magnesium Anodes

Product Overview

Description

High Potential sacrificial anode Mg Alloy ASTM B843 M1C Casting Magnesium Anodes



      High Potential sacrificial anode Mg Alloy ASTM B843 M1C Casting Magnesium Anodes



 ♦ Specifications



High Potential Magnesium anode is used as a sacrificial anode in cathodic protection. Magnesium has the highest driving voltage of all the materials used for sacrificial anodes. if it is placed within a system that uses large amounts water, it attracts the corrosion away from other components.

Our magnesium anode all manufactured and tested according to latest international standards, such as ASTM B843 and ASTM G97,It’s available from both M1C( high Potential)or AZ63B(standard Potential)magnesium anode.

♦ Application :

High Potential Magnesium anode fight corrosion effectively and economically, and are commonly used in marine environments, soil environment,etc..They protect a variety of steel structures in salt, brackish and fresh water, including: Buried Oil gas Pipelines, Storage tanks, Boats, Ballast tanks, Bulkheads, Pilings, Heat exchangers, etc.

² Boats ² Ballast tanks ² Bulkheads ² Water storage tanks

² Pilings ² Pipelines ² Heat exchangers

Magnesium anodes corrode much more easily than the materials they are protecting, drawing the corrosion away from equipment.

♦ Chemical compositions of High Potential Magnesium Anode :

Type	Al (Max)	Mn	Cu (Max)	Ni (Max)	Si (Max)	Fe (Max)	Single impurity (Max)	Total Impurity (Max)	Mg
M1C	0.01	0.5-1.3	0.005	0.001	0.05	0.01	0.05	0.3	Remaining



♦ Electrochemical properties of High Potential Magnesium Anode:

Type	Open-circuit voltage (-V)	Close-circuit voltage (-V)Zn	Actual capacitance (A·h/kg)	Current efficiency (%)
M1C	1.70-1.75	1.58-1.62	≥1100	≥50

* We can do according to customized size and requirements.



 ♦ Structure & Dimension



* The above specification only are small part of our products list, we have much more specification size, and also special shape, size and chemical composition anodes can be manufactured according request, please contact us for more information.





 ♦ Company Simple Introduction:



We are professional manufacturer and has twenty years experience in anti corrosion industry. Our main products includes

• Magnesium casting & Extruded Anode, Magnesium Ribbon anode
• Aluminum Anode
• Zinc anode, Zinc Ribbon Anode,
• High Silicon Cast-Iron Anode
• Epoxy Coated Steel Reinforcing Bar
• Ant-corrosion Tapes

Our products are widely used to many important projects and water heater factories, Hongkong-Macau-Zhuhai bridge, Hangzhou Bay bridge, and Sinopec, Haier, AOSmith etc,.





63B Casting Magnesium Rod Anodes for water heaters, Extruded Magnesium Rod Anodes





Q.What information will be needed if I want a quotation?

A: Materials contents(Chemical Compositions) and the size of models. Special structures with drawing, Qty and delivery time.



Q. Can we visit your company/factory before place the order?

A: Welcome to visit us in China. Hopefully it will be a happy journey here.



Q: How does your factory do regarding quality control?

A: Quality is base of the company life. We working on new materials industrial for more than 20 years.



Q. What do Magnesium sacrificial anodes do?

A. Magnesium anode is used in the technical method of electrochemistry cathode protection. theory is from that connect with the protected metal body ,with the exhausting and dissolving of negative metal material or alloy ,protective curer body  will be protected from corrosion . Mg anode can produce higher quality potential power, is ideal sacrificial materials.
