This 12 inch Neodymium woofer Speakers offers outstanding efficiency , high sensitivity 98dB. Its very high power handling(450W RMS ) and Xmax capabilities make it suitable for any pro audio speaker enclosure, including LINE ARRAY SPEAKER SYSTEM.

Specification


Features :


- 12 inch midbass speaker with neodymium magnet and carbon cone
- 1800W continuous program power capacity / 450W RMS
- 98dB sensitivity 1W/1M
- 50hz-4.5khz Frequency response
- Neodymium magnet
- 3 inch/75mm copper voice coil
- Carbon cone and dust cap to give higher efficiency

Speccification :

\t
Specification
\t
Nominal diameter
\t
300/12
\t
mm/inch
\t
Nominal impedance
\t
8
\t
ohm
\t
Min impedance
\t
5.2
\t
ohm
\t
Frequency response
\t
50-4.5k
\t
Hz
\t
Magnet material
\t
Neodymium
\t
\t
Sensitivity (1w/1m)
\t
98
\t
dB
\t
RMS power handling
\t
450
\t
Watts
\t
Continuous power handling
\t
1800
\t
Watts
\t
Voice coil diameter
\t
75/3
\t
mm/ inch
\t
Winding material
\t
Copper
\t
\t
Cone material
\t
Carbon
\t
\t
Surround material
\t
Cloth
\t
\t
T/S Parameter
\t
Fs
\t
52.6
\t
Hz
\t
Re
\t
5.2
\t
Ω
\t
Qes
\t
0.45
\t
\t
Qts
\t
0.44
\t
\t
Qms
\t
13.45
\t
\t
Vas
\t
49.7
\t
L
\t
Rms
\t
1.8
\t
kg/s
\t
Cms
\t
0.13
\t
mm/N
\t
Mms
\t
72.8
\t
gr
\t
BI
\t
16.6
\t
N/A
\t
Rp
\t
86.9
\t
Ω
\t
Lp
\t
40.5
\t
mH
\t
Cp
\t
438.4
\t
uF
\t
Le
\t
0.6
\t
mH
\t
Xmax
\t
7
\t
mm
\t
Mounting information
\t
Overall diameter
\t
312/12.3
\t
mm/inch
\t
Bolt Circle diameter
\t
295/11.6
\t
mm/inch
\t
Baffle Cutout diameter
\t
279/11
\t
mm/inch
\t
Depth
\t
145/5.6
\t
mm/inch
\t
Flange thickness
\t
13/0.51
\t
mm/inch
\t
Shipping information
\t
Net weight
\t
3.8
\t
KG
\t
Shipping weight
\t
4.5
\t
KG
\t
Shipping box
\t
340x340x170
\t
mm
