Product Overview

Description


Product Description

fiberglass floor plastic road drain cover grating grates


6# quartz sand (fine sand)

5# quartz sand (medium sand)

6# quartz sand (coarse sand)

\t

Parameters

\t
Type
\t
fiberglass floor plastic road drain cover grating grates
\t
Material
\t
ECR Glass Fiber + Resin  (ORTHO,ISO,VE,PHENOLIC)+Filling (ATH)
\t
Mesh Size
\t
38*38*38mm，40*40*40mm, etc. can be customized (pls check detail as below form)
\t
Color
\t
According to RAL Book.Yellow, Orange, Blue, Green, Grey, etc. can be cutomized
\t
Surface
\t
Gritted,  Smooth, Concave, Solid Top Covered

Anti-Fire/Corrosion/UV

Light Weight/High Strength

Safety/Easy Installation

Size-Molded Grating
\t

Mesh Size(mm)

\t

Thickness (mm)

\t

Bar Thickness(mm)

\t

Standard Panel Size(mm)

\t

38x38

\t

13

\t

6.0/5.0

\t

1220x3660,1220x4000,1220x2440,921x3055

\t

14

\t

6.0/5.0

\t

1220x3660,1220x4000,1220x2440,921x3055

\t

15

\t

6.0/5.0

\t

1220x3660,1220x4000,1220x2440

\t

20

\t

6.0/5.0

\t

1220x3660,1220x4000,1524x4010,997x3012

\t

25

\t

6.5/5.0

\t

1220x3660,1226x4010,1524x4000,1530x4010,1997x3012

\t

30

\t

6.5/5.0

\t

1220x3660,1220x4010,1524x4010,921x3055

\t

38

\t

7.0/5.0

\t

1220x3660,1220x4010,2100x4240,998x4010,1220x2440

\t

50

\t

9.5/7.5

\t

1220x4010,1220x3666,1230x4010,1220x2440,921x3055

\t

60

\t

10.5/8.5

\t

1230x4010

\t

70

\t

11.0/9.0

\t

1230x4010

\t

40x40

\t

25

\t

7.0/5.0

\t

1007x3007,1007x4007,1247x4047,1527x4047

\t

30

\t

7.0/5.0

\t

1527x4047,1007x3007,1247x4047

\t

38

\t

7.0/5.0

\t

1527x4047,1247x4047,1007x3007,1007x4047

\t

40

\t

7.0/5.0

\t

1527x4047,1007x3007,1007x4047,1247x4047

\t

50x50

\t

15

\t

6.0/5.0

\t

1228x4020,1220x3660,1220x2440

\t

40

\t

6.8/5.0

\t

1787x4530,1225x4530

\t

25

\t

7.0/6.0

\t

1220x3660,1226x4020,1220x2440,915x3050

\t

50

\t

8.0/6.0

\t

1524x4000,1220x3660,1220x2440,1220x4000

\t

83x83

\t

38

\t

7.0/5.0

\t

1007x4007,1007x3007,1007x4255

\t

40

\t

7.0/5.0

\t

1007x4007,1007x3007,1007x4255

\t

13x13/40x40

micro mesh

\t

25

\t

6.5/4.5/5.0

\t

1247x4047,1007x3007,1007x4047,1530x4047

\t

30

\t

6.5/4.5/5.0

\t

1527x4047,1247x4047,1007x3007,1007x4047

\t

38

\t

6.5/4.5/5.0

\t

1527x4047,1247x4047,1007x3007,1007x4047

\t

19x19/38x38

mini mesh

\t

25

\t

6.5/5.0

\t

1220x3660,1220x2440,921x3055,1226x4007,1268x4007

\t

30

\t

6.5/5.0

\t

1220x3660,1220x2440,921x3055,1220x4000,1530x4047

\t

38

\t

6.5/5.0

\t

1220x3660,1220x2440,921x3055,1220x4000,1226x4010

\t

20x20/40x40

mini mesh

\t

14

\t

6.5/5.0

\t

1007x3007,1247x4047

\t

22

\t

6.5/5.0

\t

1527x4047,1007x3007,1247x4047

\t

25

\t

6.5/5.0

\t

1527x4047,1247x4047

\t

30

\t

7.0/5.0

\t

1527x4047,1007x3007,1007x4047,1247x4047

\t

38

\t

7.0/5.0

\t

1527x4047,1007x3007,1007x4047,1247x4047

\t

40

\t

7.0/5.0

\t

1527x4047,1007x3007,1007x4047,1247x4047

\t

25x25/50x50

mini mesh

\t

50

\t

8.0/6.0

\t

1532x4020

\t

26x26/52x52

mini mesh

\t

30

\t

7.0/6.0

\t

1530x4000,1532x4050

\t

38

\t

6.0/5.0

\t

1517x4015

\t

25x50

\t

38

\t

11.0/9.0

\t

1220x1835

\t

50

\t

12.0/9.0

\t

1220x1835

\t

25x100

\t

25

\t

7.0/5.0

\t

1220x3660,915x3050

\t

38x100

\t

38

\t

8.0/6.0

\t

1226x3665,1530x4047,921x3050

\t

25x152

\t

38

\t

8.0/6.5

\t

1220x3660,1220x2440,1220x4124,921x3050

\t

38x152

\t

38

\t

8.0/6.0

\t

1220x3660,1220x2440,915x3050

Application-Grating

Walkway / Platform Grating

Car Wash Floor Drain Grating

Stair Grating

Farm & Breed Industry Floor Grating

Decorative Ceiling Roofing Grating

Tree Protective Grating

Fence Grating

Drain Grating

Marine Industry Platform Grating
