Main Application: Junzhuo Single Arm Mixers are suitable for mixed powder or paste material in pharmaceutical, chemical, food and other industries.
Working Principle: Through the mechanical transmission, CH mixers offer durable, reliable and more efficient mixing.
Technical Parameter
Model
Max Loading Volume
Operation Volume
Rotatio Speed
Motor Power
Discharge Motor Power
Discharge Angle
Overall Dimension
Approx Weight
CH-1
1.3L
1L
24rpm
0.2kw
By Manual
120
430*220*
30kg
CH-30
33L
30L
24rpm
0.75
360
1020*420*600
120kg
CH-50
55L
50L
24rpm
1.1kw
360
1050*500*800
200kg
CH-100
110L
100L
24rpm
3kw
0.55kw
360
1400*500*1000
350kg
CH-150
170L
150L
24rpm
4kw
0.75kw
360
1660*600*995
600kg
CH-200
220L
200L
24rpm
5.5kw
0.75kw
360
1660*600*995
620kg
CH-300
320L
300L
22rpm
5.5kw
1.1kw
360
2200*680*1100
800kg
CH-400
420L
400L
22rpm
7.5kw
1.5kw
360
2400*710*1200
850kg
CH-500
525L
500L
24rpm
11kw
2.2kw
360
2400*850*1260
920kg
CH-1000
1050L
1000L
18rpm
18.5-22KW
3kw
360
3150*1000*1500
2100kg
Working Principle
Company Profile
Since 2008
JUNZHUO MACHINERY was set up to 2008 with the objective to develop & provide process technology offering of international standards. We keep the mission of staying committed to innovation and by consistently exceeding customer expectations, helping companies do business more efficiently and profitably. Our customers range from small family run operations to famous companies. Regardless of customer size, our philosophy for each is the same, to achieve a creative process solution that efficiently and economically meets the requirements of the application with a smiling service.
Our dry granulation system comprising of roll compactor and cone mill, wet granulation system including of oscillating granulator,basket extruder and screw granulator. All of the products have scale up capability from lab to production equipment, we make over 90% of our machine parts in-house, ensuring stringent quality control. JUNZHUO MACHINERY also provide mixing machine, crushing machine, grinding machine, sifting machine and other machines. The main motto of the company is to deliver best quality products at most economic price & excellent customer service after delivery.
Product packaging
Spare Parts
It will be packed into a wodden case, such as motor, screen sieves, O-ring and so on.
