4-20mA YTC Smart Control Valve Positioner YT-2500/ YT-2550





Introduction:





YT-2550 Smart Valve Positioner accurately controls valve stroke, according to input signal of 4-20mA, which is being input from the controller. In addition, built-in micro-processing operator optimizes the positioner's performance and provides unique functions such as Auto calibration, PD control.











































































































Item.Type



YT-2500/ YT-2550



Input Signal



4-20mA DC



Supply Pressure



0.14-0.7MPa(1.4-7bar)



Stroke



Linear Type



10-150mm



Rotary Type



0-90°



Impedance



Max.500Ω@20mA DC



Air Connection



NPT1/4



Gauge Connection



NPT1/8



Conduit



PF1/2(G1/2)



Ambient Temp



Operating Temp



(-30℃~80)/(-22~176°F)



Explosion Temp



(-40℃~60 T5)/(-40℃~40 T6)



Linearity



±0.5% F.S



Hysteresis



±0.5% F.S



Sensitivity



±0.2% F.S



Repeatability



±0.3% F.S



Air Consumption



Fail Freeze



0.01LPM(sup=0.14MPa)



Fail Safe



6LPM(sup=0.14MPa)



Flow Capacity



60LPM(sup=0.14MPa)



Output Characteristics



Linear,EQ%,Quick Open user set(16 Point)



Material



Stainless Steel316



Enclosure



IP66



Explosion Proof Type



Exia IIC T5/T6



Weight



2.9kg(6.4Ib)
