This type of shoe making machine lamination machine is Widely used to laminate apparel fabrics, nonwoven, leather, foam, woven fabric, TPU, PU, PE, EVA, PVC, Applications in industries of garments, footwear, cap, luggage, upholstery, home textile.
Suitable Industry: lingerie , underwear, luggage, shoes-making, handbags, sofa, car cushions and etc.
Machine parameter
Power supply/power 45KW Heating roller 1500mm/1800mm customized Working Width 1800mm Working speed 0-45yards Machine Size ( L*W*H) 7000mm*2500mm*2300mm Weight 3000kg
Features:
1.There is a glue scraping blade to scrape the glue evenly onto fabric and the unique glue channel design facilitates the cleaning of the glue after lamination.
2.All the heating pipes in the drying roller are made of stainless steel and the temperature of the heating drying roller can be as high as 160 celcius degree, and even 200 celcius degree. There are usually two sets of heating system in the drying roller. The heating will automatically change from two sets to one set. It is safe and energy saving.
3.Conveyor system can be installed for materials in sheets form.
