High Frequency Digital Radiography System (25KW, 200mA) medical xray x ray machine CE approved

Item

Parameter

High Frequency X-ray Generator

Power Output

Inverter Frequency

Tube Voltage

Tube Current
mAs

26KW

60kHz

40-130kV
200mA

0.4~360mAs

X-ray Tube

Dual-focus

Thermal capacity
Speed of rotary anode

Small focus: 0.6     Large focus: 1.3

900kJ (1200 KHU)

3000rpm

Digital Detector

Type of detector

Field of view

Inch Pixel

Spatial resolution

Pixel size

Grayscale output

Imaging time

CCD

17”*17”

3K*3K

≥3.6LP/mm

140um

14bit

15S

Digital workstation

Image acquisition system :

Image processing module:

Image storage and transmission:

Photo processing software, X-ray synchro Control software, motion control software

tissue equilibrium, W/L adjustment, Gamma correction, interest district, reversed phase, noise reduction, smooth, sharpen, pseudo color, Edge extraction, shadow compensation, filter neuclear, single window, dual-window, four windows, movement, right rotated 90°,left rotated 90°,level mirror image, vertical mirror image, magnifying glass, image zooming, reset, layer information, label character, drawing label, length measurement, angle measurement, rectangular length, rectangular area, elliptic length, elliptic area

Dicom transmission

Dicom Worksite SCU

Film printing

Mass storage(hard disk, compact disk)

Mechanical structure performance

Motorized vertical travel

Anode to Screen range

Rotation range

450mm-1700mm(motorized control)

1000mm-1800mm(motorized control)

-40°~+130°(motorized control)

Others

Supply power

380V 50Hz(220V 50HZ is also available)

No.

Item

Quantity

1

Newly designed U-arm frame

1

2

High frequency and high voltage Combined X-ray generator

1

3

High frequency inverted power supply electronic cabinet

1

4

Remote control

1

5

17’’*17” digital detector

1

6

19” High-definition LCD display

1

7

Digital workstation

1

8

Hand controller

1

9

Grid

1
