Aluminum Foil woven Fabric Flameproof Sound Absorbing Water Resistant Heat Insulators
- Category: >>>
- Supplier: Suzhou Star New Material Co. Ltd.
Share on (60693907403):
Product Overview
Description
Aluminum foil woven fabric flameproof sound absorbing water resistant heat insulator
Specification
The material provides excellent insulation: reflects up to 97% of radiant energy in addition to resisting other
types of heat transfer from conduction,convection,and radiation.The side of metalized PET/Alu forms an
effective barrier against moisture,air currents and vapors.It is economical solution in many field.
Function:
1.Water, corrosion, light can be prevented effectively.
2.for keeping warm ground, warm wall, moisture-proof floor, etc.
3.Eco-friendly .insulation,.water-proof,oil resistant, etc.
4.For construction,OEM is available.
Charateristics:
1. No nocuousnessaccording with ISO14000
2. It is a high quality material
3. Sound absorbtion, reduce noise, cushioning function
4. Water and leak proof, anti-flaming
5. Durable in use and endurable to heat, cold and chemical reaction
Usage:
1. Heat insulation and light inflecting in construction and protect both cold water and hot water pipe
2. Separation of refrigerator, warm keeping for center conditioner, and other home appliance
3. Heat insulation, sound absorption for car, train, and lab, cushion of traveling.
4. Packing for special products and cold storage
Item | Aluminium foil+ woven fabric+(Aluminum foil) |
Thickness | 0.14-0.18mm |
Roll Width | 1.2m(can be 20mm-1530mm) |
Roll Length | 50--6000m |
Available grade | plain lacquered, heat sealable |
MOQ | 100 Square meters |
Characteristics | High gloss, perfect stiffness, excellent barrier property, proer brightness, excellent ink adhesion, |
Packing | by PE bag, bulk on container. Diameter of internal paper core of rolls: 1.5 "or 3 " |
Application |
(1),Roof,Attic,Underlay & floor InsulationUnder Concrete & wood.
(2),Crawl Space,Stud Wall,Metal Frame Building Insulation |
Payment Term | By T/T, 30% as prepayment, the balance will be paid before loading containers after production |
Delivery Time | Containers can be loaded within 20 days on receipt of prepayment |
Technical Parameters:
Aluminum foil woven fabric flameproof sound absorbing water resistant heat insulator
Material Structure: AL/ woven cloth/AL | ||
Roll Width:1.2m*100m (width & lenth can be customized) | ||
PROPERTIES | TEST DATA | UNIT |
Thickness | ±0.15 | mm |
Weight | ±138 | g/m2 |
Emissivity | 0.03-0.04 | COEF |
Thermal conductivity | 0.036 | w/m0 |
Apparent Density | 73 | kg/m2 |
Reflectivity | 96-97 | % |
Water Vapour Transmission | <2.0 | Ng/NS |
Corrosion | doesn't generate | |
Tensile Strength(MD) | 290 | Mpa |
Tensile Strength(TD) | 240 | Mpa |
Bursting Strength | 740 | N |
flame spread index | 6s | / |
Product Introduction
Aluminum foil woven fabric flameproof sound absorbing water resistant heat insulator
Installation
- Homes
- Metal & Steel buildings
- Roof Underlayments
- Attics
- Ceilings
- Floors
- Basement Walls
- Polst frame buildings
- Garage doors
- Pole barns
- Poultry barns
- Crawl spaces
Production Line
Aluminum foil woven fabric flameproof sound absorbing water resistant heat insulator
We have 5 different production lines in 3 different cities, which are in Suzhou, Shenzhen and Tianjin.
so the delivery time and delivery place is not a big problem, we can make mass production and
delivery as soon as possible.
Packing & Loading
Aluminum foil woven fabric flameproof sound absorbing water resistant heat insulator
Test Report
Aluminum foil woven fabric flameproof sound absorbing water resistant heat insulator
Factory View
Aluminum foil woven fabric flameproof sound absorbing water resistant heat insulator
Established in 1999,New Star International Group Limited owns four entity factories,which are Shenzhen
Star New Material Co., Ltd.,Suzhou Star New Material Co., Ltd., Suzhou Sida'er New Materials Co., Ltd.,
Tianjin Star New Material Co., Ltd.,
New Star International Group Limited has its own independent industrial parks covering more than 60,000
square meters and employees more than 700 workers after more than ten years of effort and development.
Currently,our products are exported to over 30 countries such as Germany, America, Canada, Italy, Brazil,
Japan, Australia,Indonesia,Malaysia, and others.
