650w High quality Stainless Steel Electric Drainage Submersible Dirty Water Sump Pump Float Switch

Product Overview

Description

650w High quality Stainless Steel Electric Drainage Submersible Dirty Water Sump Pump Float Switch





It is ideal for general submersible water applications such as able to drain infiltrating water, cellars to reservoirs, clean or slightly dirty water and for garden irrigation. emptying spas, hot tubs, pools, flooded basements or garden.



Please note that it is not suitable for 24 hour continuous operation such as powering garden water features or fountains as other sellers may imply.



Features



Fully submersible

Float switch - automatic switch off when water level drops ( from 7cm to 53cm )

Build-in overload motor protector with automatic reset

Insulation Class B/F
Protection IPX8

Pump body: stainless steel

Impeller: PP/stainless steel if request
Shaft with rotor: 45# Carbon Steel/Stainless steel if request

Liquid temperature: Up to  35°C



Specifications



MODEL	POWER (W)	MAX HEAD (M)	MAX FLOW (L/H)	MAX SUB. DEPTH (M)	MAX GRAIN SIZE	CABLE AND LENGTH (M)	QTY/20”CTN (PC)
TP01099	400	5.0	7500	8	35MM	H05RN-F3G1.0mm2X10m	2040
TP01100	550	7.0	10500	8	35MM	H05RN-F3G1.0mm2X10m	2040
TP01101	650	7.5	11500	8	35MM	H07RN-F3G1.0mm2X10m	2040
TP01102	750	8.0	12500	8	35MM	H07RN-F3G1.0mm2X10m	2040
TP01103	810	8.0	13000	8	35MM	H07RN-F3G1.0mm2X10m	2040
TP01104	900	9.0	14000	8	35MM	H07RN-F3G1.0mm2X10m	2040
TP01105	1100	10.0	15000	8	35MM	H07RN-F3G1.0mm2X10m	2040
