Single Color Sheet fed Offset Printing Machine
Single Color Sheet-fed Offset Printing Machine
Single Color Sheet-fed Offset Printing Machine

Single Color Sheet fed Offset Printing Machine

Share on (60694538477):


Price:$62,000.00

Quantity:


Product Overview

Description


Product Description

Product Application

Specifications

ZX1020 Single Color Sheet-fed Offset Printing Machine

1. Single color

2. Max.printing area: 1020*700mm

3. High quality


Detailed Product Description:

1. The main machine has the buttons of positive point, negative point and low speed operation, which inconvenient for the operator to observe and adjust the machine and scrub the roller.

2. The paper-transfer device adopts conjugate cam so as to ensure the paper-transfer smooth, accurate, reliable and with little noise of the operation of the machine.

3. It adopts the big roller which has good pressure, so the paper deforms little, especially suitable for the thick-paper printing.

4. The gear is out-movable, which is convenient for repairing.

5. The devices of half-automatic plate-mounting and quick plate-griping can reduce the auxiliary time of the printing work.

6. It adopts the automatic centralized lubricating system of set-point, fixed-quantity and fixed-time to make the lubrication full, which strengthens the reliability of safe operation of the machine

7. The pressure of the ink-roller and the water-roller adopts the adjustment of worm-and gear device inside the wall plate, the adjusting range is large and the operation is very convenient.

8. It adopts the adjustable vent fan, which make paper-reception smooth and in place.

9. It has been added the powder-spray device to make the ink dry quickly.

Printing color
Single color
Single color
Max.sheet size
720×1040
mm
Min.sheet size
393*546
mm
Max.printing area
1020×700
mm
Max.circulate speed
8000
s/h
Printing sheet thickness
0.04-0.45
mm
Plate size
940*760*0.3
mm
Rubber cloth size
950*975*1.9
mm
Max.feeder pile capacity
900
mm
Max.receiver pile capacity
900
mm
Total power of motors
10.5
kw
Machine weight
7000
kg
Machine overall dimension
3800*2100*2125
mm
Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery
Packaging
Size
3800(L) * 2100 (W) * 2125 (H)mm
Weight
7000kg



Packaging Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Our Company

We are a professional company which manufactures and sells printing machines and office equipment. Our high quality products and perfect service have enjoyed a high reputation in the industry. Moreover, they sell well all over the world.

Our products include all kinds of offset machines, cutting machines, binding machines, bill printing machines, digital stencil duplicator machines, digital print machines, spray printing machines, print finishing machines and other kinds of printing, packing, advertisement and office equipment.
