Product Overview
Description
Product Description
10years experience for busbar machine
Features:
1.Low maintenance, longer service life.
2.The cut surface is smooth and neat, no droop, no burrs, no waste.
3.Rotary turret punching unit installed 6pc (4pcs and 8pcs ) dies, less replacing, high efficiency.
4.It can punch cut and bend in the same time.
5.Contacted by PLC system, bending precision at ±1°,repeat precision at ±0.3°.
6.Easily to be moved with four casters.
7.Manual button and foot switch are optional.
8.Can customize the punching dies you need.
Function:
1.Bending at vertical and horizontal direction.
2.Punching for round and oblong hole.
3.Cutting busbar.
4.Special for embossing, knurling, twisting, cable joints pressing.
Detail Date
| Function | Item | JL-200160 | JL-200200 | JL-200260 |
Punching | Max. Punching Force (KN) | 300 | 500 | 800 |
| Punching Diameter Range (MM) | ∅4.3-∅25 | ∅4.3-∅34 | ∅4.3-∅36 | |
| Max. Thickness (MM) | 12 | 16 | 20 | |
| Max. Width (MM) | 160 | 200 | 260 | |
Shearing/Cutting | Max. Shearing Thickness (MM) | 12 | 16 | 20 |
| Max. Shearing Width (MM) | 160 | 200 | 260 | |
Vertical Bending | Max. Bending Force (KN) | 300 | 500 | 800 |
| Max. Bending Thickness (MM) | 12 | 16 | 20 | |
| Max. Bending Width (MM) | 160 | 200 | 260 | |
Horizontal Bending | Max. Bending Width (MM) | 120 | 120 | 120 |
| Max. Angle (Degree) | 90° | 90° | 90° | |
CNC Precision | Bending Precision | ±1° | ±1° | ±1° |
| Repeat Bending Precision | ±0.3° | ±0.3° | ±0.3° | |
| Out Dimension | MM | 1750*1350*1420 | 1920*1550*1500 | 2150*1750*1500 |
| Power | KW | 3*4kw | 3*5.5kw | 3*5.5kw |
| Weight | KG | 1400 | 1650 | 1970 |
