TS D001 factory Momentary 6*6 mm RoHS reach tact switch 4 pin DIP type for Remote Control push button tactile switch

Share on (60696300385):


Price:

Quantity:


Product Overview

Description



Product Description


 TS-D001 Momentary 6mm tact switch 4 pin DIP type for Remote Control  push button switchFirst PageTS-D001TS-D001P-1TS-D001

























































Model No.TS-D001
Terminal TypeSMD/SMT
Switch Rating50mA DC 12V
Operation Travel0.25±0.1mm
Operation TpyeMomentary
Operation Force160/180/250/400 gf
Operation Life300,000 Cycles
Contact Resistance≤100mΩ max
Insulation Resistance≥100MΩ/m  DC 250V
Dielectric StrengthAC 250V/m 50Hz
Operation Templerature -30℃  to + 85℃
Operation Humidity25-85% RH
Solder Ability260±5℃ for 3 seconds












FAQ





1. Q: Are you a factory or trading company?


A: We are factory and produce all the products by our self.





2. Q: I need your price list of all your products, do you have a price list ?


A: We do not have a price list of all of our products. Because we have so many items,and it’s impossible to mark all of their price on a list. And the price are always changing because of the producing cost.If you want to check any price of our products,  please feel free to contact us. We will send offer to you soon!





3. Q: I can’t find the product on your catalogue, can you make this product for me?


A: Our catalogue shows most of our products,but not all.So just let us know what product do you need,


and how many do you want. If we do not have it, we can also design and make a new mould to produce it.  For your reference,making a ordinary mould will take about 35-45days.





4. Q : Can you make customized products and customized packing?


A: Yes.We made a lot of customized products for our customer before.(mainly wire harness)


And we made many moulds for our customers already.


About customized packing, we can put your Logo or other info on the packing.There is no


problem.Just have to point out that ,it will cause some additional cost.





5. Q: Can you provide samples ? Are the samples free ?


A: Yes,we can provide samples.Normally,we provide free samples for test or quality checking.


But you have to pay for the shipping cos.If you need many items, or need more qty for each item,  we will charge for the samples.





6. Q : What about your delivery time?


A: We have a lot of products in stock.We can send the stock products in 3 work days.


If without stock,or stock is not enough, we will check the delivery time with you.





7. Q : How to ship my order ? Is it safe?


A: For small package, we will send it by Express, such as DHL,FedEx,,UPS,TNT,EMS.That’s a Door to Door service.


For big packages, we will send them by Air or By sea.We will use good packing and ensure the safety. We will be responsible to any product damage caused on delivery.
