IGBT Inverter 220volt Mig/Tig/MMA welding Machine Promig 200syn
- Category: MIG Welders >>>
- Supplier: Hangzhou Topwell Technology Co. Ltd.
Share on (60698306689):
Product Overview
Description
Product Features
professional tig mig mma mag GMAW welder welding machine PROMIG-200SYN
Q&A
Customer Review
Packages available
Technical Data
| Item No | PROMIG-200SYN PULSE |
|---|---|
| Rated Input Voltage | 1PH ~ 230V ±15% |
| Max. Load Power Capacity | 8.75KVA |
| Rated Duty Cycle(40℃) 35% | MIG: 200A/24V |
| MMA: 200A/28V | |
| TIG: 200A/18V | |
| 100% | MIG: 160A/22V |
| MMA: 160A/26.4V | |
| TIG: 160A/16.4V | |
| Welding Current/Voltage Range | MIG: 10A/14.5V ~200A/24V |
| MMA: 20A/20.8V~200A/28V | |
| TIG: 5A/10.2V~200A/18V | |
| Open Circuit Voltage | 70V~80V |
| Power Factor | 0.8 |
| Efficiency | 80% |
| Wire-feed Mechanism | 2 Rollers |
| Wire-feed Speed Range | 2-18m/min |
| Wire Spool Capacity | 200mm (5kg) |
| Filler Wires Ø (mm) Fe, Ss | 0.6~1.0 mm |
| Dimension: | 490x230x385mm |
| Weight | 20KG |
