CSF15A4S D three terminal SMD self control fuse 36Vdc 15A overcurrent overvoltage double protection

Product Overview

Description

best choice CSF15A4S-D three terminal SMD self control fuse 36Vdc 15A overcurrent overvoltage double protection



The structure application area specification of best choice CSF15A4S-D three terminal SMD self control fuse 36Vdc 15A overcurrent overvoltage double protection series:



Some information aboutbest choice CSF15A4S-D three terminal SMD self control fuse 36Vdc 15A overcurrent overvoltage double protection :

Product name	CSF15A4S-D self control fuse 36Vdc 15A
Rated current	10A,12A,15A
Rated voltage	36Vdc
Operated voltage	10.5-19.6V
Material	ceramic substrate
Size	5.4*3.2*1.35mm
Feature	three terminal
Application	Lithium Ion Battery, computer, phone, tablet, camera, power tool
Color	as photo
Package	standard



The base principle of best choice CSF15A4S-D three terminal SMD self control fuse 36Vdc 15A overcurrent overvoltage double protection series:

Good electrical performance of best choice CSF15A4S-D three terminal SMD self control fuse 36Vdc 15A overcurrent overvoltage double protection series:

1: High current capacity, rated current > 10A, excellent performance in the use of large current;

2: The movement performance is stable and disconnects completely;Electrode adopts ceramic circuit board technology, welding is reliable;

3: Small size, suitable for high density installation;Quick response and high sensitivity;Three layers of the electrode;

4: (Silver, nickel, tin) easy to weld glass uranium outer protection, structure is reliable,work is stable; Packing and packing for automatic pasting.
