10pin to 40 pin ribbon cable with 1.0mm idc connector flat cable wire harness

     Our company is specializing in the production of various types of gray IDC ribbon cable assembly; hard disk IDC ribbon cable assembly; LED display IDC ribbon cable assembly; Computer IDC ribbon cable assembly, IPC IDC ribbon cables assembly, etc.

IDC ribbon cable is widely used in Smartphone & Cell Phone / Notebook PC & Tablet PC / Flat panel display / Professional TV camera / Digital camera & Video camera / Security & Network camera / Multifunction printer / Printer / AV equipment / Medical equipment / Digital measurement instrument / Robot / Industrial / Projector / Handy terminal / Amusement / Car electronics.

Product Name:  IDC connector to IDC connector cable assembly

Red IDC connector pitch: 2.54mm Male IDC connector

Gray IDC ribbon cable pitch: 1.27MM (Options: 0.635MM 1.0MM 2.0MM 2.54MM)

Gray IDC ribbon cable Specifications: 28AWG (Options: 32AWG 30AWG 26AWG 24AWG)

Copper structure material: the first after the first twist plated stranded copper clad aluminum magnesium wire 7 strands of copper wire --12 shares

Copper wire Conductor:  7/0.12MM (Options: 7/0.08MM, 7/0.09MM, 7/0.1MM, 7/0.16MM, 7/0.2MM, (7 means 7 strands copper wire)]

Jacket color: gray with conventional printing with red edge, and another color, black and yellow, to be ordered!

Conductor diameter: 0.12 ± 0.005mm

Conductor Elongation: 18% ↑

Conductor cross-sectional area: 0.36mm2

Conductor twisted away from 10.7mm ↓

The average thickness of the insulator minimum 0.10mm 0.23mm

Wire thickness 0.9 ± 0.05mm

Insulator elongation 100.00%

Insulator tensile strength 1.066Kg / mm2

Spark test 3.0KV / 0.15SPC ↑

Withstand Voltage: 2KV 10mA /

Conductor resistance ≤237 ohms / RM ↓

Insulation resistance ≥100m ohm / RM ↑

Capacitance 40PF / M

Impedance of 100 ohms

Operating temperature: -40 °C ~ + 105 °C

Insulation Jacket: Environmental PVC 45P (RoHS) 8058 Grey

Testing requirements:

Good appearance, plastic injection molding defects may not have

Metal parts may not have scratches, deformation and other defects

Off performance to meet the requirements

1) Professional wire harness manufacturer for home appliance, Electronic, industrial control, medical and so on. We have good business with some top 500 future company, like Lenovo, Huawei, HP, Eaton, etc.

2) Our wire complies with UL/VDE/CEA/CCC/CE certification; all comply with above ROHS 2.0. Support customer especially request like no red phosphorus. Our company has got ISO2000 certificates.

3) We accept OEM/ODM design, welcome any customized cable too, whenever you have 500pcs or 100K pcs demand, we will reply you quickly and quote you best prices if we can support.

4) Strict quality control, Passed ISO2000 Quality control system, All the products are 100% test before delivery.

If you don’t find the exact items of your needs, please reach us for more details.

Why choose us?

 1.   Over 10 years manufacture experience, and many years export experience.

2.   We value every inquire send to us, ensure quick and competitive offer.

3.   We put your order into our tight production schedule, ensure you punctual delivery time.

4.   We are a sales team, with all technical support from our engineer team.

After-sales service:

    1. We deal with you complains within 24 hours.

    2. Production configuration design using modular approach can be developed and produced according to user need all kinds of special speciation production to meet the diverse need of the market.

    3. All staffs in our company with philosophy of “Integrity, dedication, truth-seeking, enterprise”, would be dedicated to provide high quality service and products for you, and wish to create better future with you!

Q: Do you have stock?

A:  We don’t have stock; we’ll start production after receiving PO.

Q: How can I get quotation?

A: It is helpful for us to recommend the right item if we know your detail description or specifications. Drawing and quotation will be sent accordingly.  Of course, it is best if we have your drawing.

Q: Can I have samples?

A: Samples are available for evaluation.

Q: Is OEM & ODM available?

A: OEM&ODM are welcome.
