New & Original Omron CP1H PLC controller CP1H-X40DR-A CP1H-X40DT-D CP1H-X40DT1-D CP1H-XA40DR-A CP1H-XA40DT-D CP1H-XA40DT1-D CP1H-EX40DT-D CP1H-Y20DT-D





• Pulse output for 4 axes. Advanced power for high-precision positioning control.

• High-speed counters. Differential phases for 4 axes. Easily handles multi-axis control with a single unit.

• Eight interrupt inputs are built in. Faster processing of approximately 500 instructions speeds up the entire system.

• Serial communications. Two ports. Select Option Boards for either RS-232C or RS-485 communications.

• Ethernet Communications. Enabled by using an Option Board. Two ports can be used as an Ethernet port to perform. Ethernet communications between the CP1H and a host computer.

• Built-in Analog I/O. XA CPU Units provide 4 input words and 2 output words.

• USB Peripheral Port. Another standard feature.

• The structured text (ST) language. Makes math operations even easier.

• Can be used for the CP1W series and CJ series Unit. The extendibility of it is preeminently good.

• LCD displays and settings. Enabled using Option Board.



Omron PLC CP1H Units

CPU Unit	Specification				Model	Standards
	Power Supply	Output Method	Inputs	Outputs		UC1, N, L, CE, KC
CP1H-X CPU Units	AC power supply	Relay output	24	16	CP1H-X40DR-A
	DC power supply	Transistor output (sinking, NPN)			CP1H-X40DT-D
		Transistor output (sourcing, PNP)			CP1H-X40DT1-D
CP1H-XA CPU Units (w/ Built-in Analog I/O)	AC power supply	Relay output	24	16	CP1H-XA40DR-A
	DC power supply	Transistor output (sinking, NPN)			CP1H-XA40DT-D
	DC power supply	Transistor output (sourcing, PNP)			CP1H-XA40DT1-D
CP1H-Y CPU Units	DC power supply	Transistor output (sinking, NPN)	12	8	CP1H-Y20DT-D
CP1H-EX CPU Units (w/ Built-in Ethernet port)	DC power supply	Transistor output (sourcing, PNP)	24	16	CP1H-EX40DT-D







Options for Omron PLC CP1H Units



Name	Specifications	Model	Standards
RS-232C Option Board	Can be mounted in either CPU Unit Option Board slot 1 or 2.	CP1W-CIF01	UC1, N, L, CE, KC
RS-422A/485 Option Board		CP1W-CIF11	UC1, N, L, CE, KC
RS-422A/485 (Isolated-type) Option Board		CP1W-CIF12	UC1, N, L, CE, KC
Ethernet Option Board	Can be mounted in either CPU Unit Option Board slot 1 or 2.	CP1W-CIF41	UC1, N, L, CE, KC
LCD Option Board	Can be mounted only in the CPU Unit Option Board slot 1.	CP1W-DAM01	UC1, N, L, CE, KC
Memory Cassette	Can be used for backing up programs or auto-booting.	CP1W-ME05M	UC1, N, L, CE
