Lever Operated GB ISO PN10 PN16 Flanged Steam Jacketed Ball valve

Product Overview

Description

SPECIFICATIONS FOR JACKED BALL VALVES
Pressure rating and size:	PN10 to PN16, ANSI Class150, JIS 10K
	DN15 to DN200
	1/2" to 8"
Material:	Body : WCB, CF8, CF8M
	Bonnet : WCB, CF8, CF8M
	Ball : A105, SS304, SS316
	Stem : F6a, SS304, SS316
	Seat : EPDM,Metal,Viton,PTFE,NBR
	Special material on request.
Operated type	Lever
Flange connection:	EN1092 & ANSI B16.5 & JIS
Type	Flange RF
