Hydraulic injection press moulding machine
- Category: Plastic Injection Machines >>>
- Supplier: Zhangjiagang,Shen,Zhou,Machinery,Co.,Ltd.
Share on:
Product Overview
Description
Hydraulic injection press moulding machine
| Technical Parameter | ||||
| Item | Unit | Parameter | ||
| INJECTION UNIT | ||||
| screw diameter | mm | 55 | 60 | 65 |
| screw L/D ratio | L/D | 22.9 | 21 | 19.4 |
| theoretical shot volume | cm*3 | 665 | 791 | 929 |
| shot weight(ps) | g | 605 | 720 | 845 |
| injection pressure | Mpa | 210 | 176 | 150 |
| theoretical injection rate | g/s | 176.5 | 210 | 245 |
| plastic capacity | g/s | 26.4 | 32.5 | 40 |
| CLAMPING UNIT | ||||
| max.clamping force | KN | 2400 | ||
| max.opening stroke | mm | 530 | ||
| space between tie bars | mm | 555x555 | ||
| mould height | mm | 200-570 | ||
| max.daylight | mm | 1100 | ||
| OTHER | ||||
| pump motor power | KW | 22 | ||
| pump pressure | Mpa | 16 | ||
| heating power | KW | 18.5 | ||
| size | m | 6.2x1.6x2.1 | ||
| net weight | t | 8 | ||
| oil tank capacity | L | 440 | ||
PRODUCT DETAILS
COMPANY INFORMATION
PRODUCTION PROCESS
CERTIFICATE
SHIPMENT
CONTACT US
FAQ
1: Are you a trading company or a manufactory?
We are a manufactory, we supply the factory price with good
quality, welcome to visit !
2:Do you have QC or any safety standards for your plastic injection
molding machine?
yes,we have established a highly strict quality control department
to guanrantee good quality.
3:Why choose our plastic injection molding machine?
High quality with competitive price
4::How about quality control in your factory?
"Quality is first, Customers are friends".
5:Can you help us with the shipment of this machine ?
Yes , with honor ,we have our special shipment company which
already cooperate
