Cement Concrete Road Paver / Mini Asphalt Paver

 Structure&Function:
1 Used for spreading, paving the bottom layer of plastic stadiums, like running track, rubberized playgrounds etc.
2 Framework: with a firm and stable welded H-type structure, and a rust-proof paint layer, it may accommodate any poor condition in the construction site.
3 Front scratch board: welded joint structure, the ground clearance is manually adjustable through a screw, which control the thickness of the floor layer. The width may be adjusted through a limiting board.
4 Driving device: the main driving system is a motor-driven caterpillar chain, with the speed smoothly controlled by a frequency converter, which is feature as stably and precisely moving ahead or back in an motion. It may be equipped with different caterpillar belt for different bottoms.
5 Walking Mechanism: the spreading machine may be manually moved or relocated through a walking mechanism consisting of advanced ratchet lever system and lift.
6 Screed: The screed has four functions, viz. the adjustment of height, angle, temperature, and vibration. The plastic cement material is vibrated, compacted and paves while passing through the screed.

If you need further information, please contact us freely, we will do our best to cooperate with you.
