Product Overview

Description

New & Original Omron S8VK-G Switching Power Supply s8vk S8VK-G06012 S8VK-G06024 S8VK-G12024 S8VK-G24024 S8VK-G24048 S8VK-G48024 S8VK-G48048

To Improve Reliability of Euipment, Start with Power Supply Selection





Model Number	Description
S8VK-G01505	Case model, Input: 100 to 240 VAC, Power rating 15 W, Output: 5 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G01512	Case model, Input: 100 to 240 VAC, Power rating 15 W, Output: 12 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G01524	Case model, Input: 100 to 240 VAC, Power rating 15 W, Output: 24 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G03005	Case model, Input: 100 to 240 VAC, Power rating 30 W, Output: 5 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G03012	Case model, Input: 100 to 240 VAC, Power rating 30 W, Output: 12 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G03024	Case model, Input: 100 to 240 VAC, Power rating 30 W, Output: 24 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G06012	Case model, Input: 100 to 240 VAC, Power rating 60 W, Output: 12 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G06024	Case model, Input: 100 to 240 VAC, Power rating 60 W, Output: 24 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G12024	Case model, Input: 100 to 240 VAC, Power rating 120 W, Output: 24 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G24024	Case model, Input: 100 to 240 VAC, Power rating 240 W, Output: 24 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G24048	Case model, Input: 100 to 240 VAC, Power rating 240 W, Output: 48 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G48024	Case model, Input: 100 to 240 VAC, Power rating 480 W, Output: 24 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions
S8VK-G48048	Case model, Input: 100 to 240 VAC, Power rating 480 W, Output: 48 VDC, Terminal blocks (Rod terminals), DIN Rail mounting, Parallel operation, Harmonic current emissions



Name	Model
Front-mounting bracket (for 15, 30 and 60 W models)	S82Y-VS10F
Front-mounting bracket (for 120, 240 and 480 W models)	S82Y-VK10F
Side-mounting bracket (for 15 W models)	S82Y-VK15P
Side-mounting bracket (for 30 and 60 W models)	S82Y-VS10S
Side-mounting bracket (for 120 W models)	S82Y-VK10S
Side-mounting bracket (for 240 W models)	S82Y-VK20S



Power rating	Input voltage	Output voltage (VDC)	Output current	Built-in fan	Model with terminal block facing upward	Model with terminal block facing forward
15W	100 to 240VAC (allowable range: 85 to 264 VAC or 120 to 370VDC)	5V	3A	None		S8FS-C01505J
		12V	1.3A			S8FS-C01512J
		15V	1A			S8FS-C01515J
		24V	0.7A			S8FS-C01524J
25W		5V	5A		S8FS-C02505	S8FS-C02505J
		12V	2.1A		S8FS-C02512	S8FS-C02512J
		15V	1.7A		S8FS-C02515	S8FS-C02515J
		24V	1.1A		S8FS-C02524	S8FS-C02524J
35W		5V	7A		S8FS-C03505	S8FS-C03505J
		12V	3A		S8FS-C03512	S8FS-C03512J
		15V	2.4A		S8FS-C03515	S8FS-C03515J
		24V	15A		S8FS-C03524	S8FS-C03524J
50W		5V	10A		S8FS-C05005	S8FS-C05005J
		12V	4.2A		S8FS-C05012	S8FS-C05012J
		15V	3.4A		S8FS-C05015	S8FS-C05015J
		24V	2.2A		S8FS-C05024	S8FS-C05024J
		48V	1.1A		S8FS-C05048	S8FS-C05048J
75W		5V	14A		S8FS-C07505	S8FS-C07505J
		12V	6.2A		S8FS-C07512	S8FS-C07512J
		15V	5A		S8FS-C07515	S8FS-C07515J
		24V	3.2A		S8FS-C07524	S8FS-C07524J
		48V	1.6A		S8FS-C07548	S8FS-C07548J
100W	100 to 120 VAC, 200 to 240 VAC (allowable range: 85 to 132VAC, 176 to 264 VAC or 248 to 373VDC (Select with the switch)	5V	20A		S8FS-C10005	S8FS-C10005J
		12V	8.5A		S8FS-C10012	S8FS-C10012J
		15V	7A		S8FS-C10015	S8FS-C10015J
		24V	4.5A		S8FS-C10024	S8FS-C10024J
		36V	2.8A		S8FS-C10036	S8FS-C10036J
		48V	2.3A		S8FS-C10048	S8FS-C10048J
150W	100 to 120 VAC, 200 to 240 VAC (allowable range: 90 to 132VAC, 180 to 264 VAC or 254 to 373VDC (Select with the switch)	5V	26A		S8FS-C15005	S8FS-C15005J
		12V	12.5A		S8FS-C15012	S8FS-C15012J
		15V	10A		S8FS-C15015	S8FS-C15015J
		24V	6.5A		S8FS-C15024	S8FS-C15024J
		36V	4.3A		S8FS-C15036	S8FS-C15036J
		48V	3.3A		S8FS-C15048	S8FS-C15048J
200W		5V	40A		S8FS-C20005	S8FS-C20005J
		12V	17A		S8FS-C20012	S8FS-C20012J
		24V	8.8A		S8FS-C20024	S8FS-C20024J
		36V	5.9A		S8FS-C20036	S8FS-C20036J
		48V	4.43A		S8FS-C20048	S8FS-C20048J
350W		5V	60A	Yes	S8FS-C35005	S8FS-C35005J
		12V	29A		S8FS-C35012	S8FS-C35012J
		24V	14.6A		S8FS-C35024	S8FS-C35024J
		36V	9.7A		S8FS-C35036	S8FS-C35036J
		48V	7.32A		S8FS-C35048	S8FS-C35048J
