Quantitative Open Bag 25kg Carbon Black Powder Packaging Machine

Product Overview

Description

Quantitative Open Bag 25kg Carbon Black Powder Packing Packaging Machine



Introduction of Quantitative Open Mouth Bag Powder Packaging Machine:

The machine can automatically complete control functions such as quantitative packaging materials, display, packaging sequence, fault alarm set weight at an organic whole, independent suspension sensors, signal stability, ensure the weighing accuracy; According to the characteristics of the powder material is not easy to flow the spiral forced blanking equipment, this machine is equipped with film bag vibrated device, make the powder material is not easy to loose, the other is equipped with dust removal, can be installed dust removal device, to keep operation workshop dust free status. The machine has rational layout, structure change the packing varieties cleaning up is very convenient; Ultrafine powder to large particles, and other materials, USES the well-known pneumatic actuators, the inlet and outlet of the cylinder pressure is adjustable, work more stable and reliable. Parts contact with material 304 stainless steel, in line with food hygiene requirements, corrosion resistance, prolong the service life of equipment. Host USES three speed fast, medium and slow feeding and special feeding structure, advanced digital frequency conversion technology, sample processing technology, anti-jamming technology, and realizes automatic error compensation and correction.

Structure of Quantitative Open Mouth Bag Powder Packaging Machine:

The packaging machine is mainly composed of automatic weighing device, transmission device, bag sewing device center four major part, computer control, etc. With reasonable structure, beautiful appearance, smooth operation, saving energy save electricity, easy to operate, the characteristics of the weighing precision.



Application of Quantitative Open Mouth Bag Powder Packing Machine:

Applicable to the flour, starch, protein powder, mineral powder, glucose powder, zinc oxide, calcium chloride, cellulose powder and other kinds of illiquid quantitative packaging powder or powder and granular materials.

Main technical parameters of Quantitative Open-bag Powder Packaging Machine:

Model	DCS-A25-F1
Precision	+/- 0.2%
Packing Capacity	3-4 bag per minute
Weighing scale	10-50kg per bag
Power Supply	220Va.c and 4N-380Va.c,50Hz (can be customized by local voltage)
Power Dissipation	4kw
Machine size	1300×1600×3300mm
Conveyor size	3000×500×150mm
Compressed Air	0.4MPa~0.6MPa
Compressed Air Consume	0.6m3  per hour
