Hot Sale 20% 60% Transparency 72W 85W Frameless Thin Film Solar Panel For Bipv
- Category: >>>
- Supplier: Xiamen Solar First Energy Technology Co. Ltd.Xiamen Ltd.
Share on (60704233976):
Product Overview
Description
Hot Sale 85W Home Frameless Window Solar Panel
| Electrical Specifications | Specification | SF-80 | SF-85 |
| Nomina power(Pm) | 80w | 85w | |
| Open Circuit Voltage(Voc) | 58.8v | 60.2v | |
| Short Circuit Current(Isc) | 1.90A | 1.97A | |
| Voltage at Max,Power(Vm) | 47.4v | 48.3V | |
| Current at Max.Power(Im) | 1.68A | 1.76A | |
| Systen Properties(at STC) | Maximum System Voltag | 1000(600UL) | |
| Limiting Reverse Current | 3.5 | ||
| Maximum Series Fuse | 3.5 | ||
| Temperature Coefficients(at STC) | Temperature Coefficients of Isc | α=0.060%/℃ | |
| Temperature Coefficients of Voc | β=0.321%/℃ | ||
| Temperature Coefficients of Pm | γ=0.214%/℃ | ||
| Mechanical Specifications | Size | 1200mm*600mm*6.8mm | |
| Area | 0.72m² | ||
| Weight | 11.8Kg | ||
| Frame | None | ||
| Lead Cable | 2.5mm² 650mm | ||
| Connectors | MC4 | ||
| Bypass Diode | 10A | ||
| Cell Type | Cadmium Telluride(CdTe) | ||
| Cover Type | 3.2mm normal Glass Laminated | ||
| Encapsulation | EVA//Edge Seal | ||
