Automatic Glass Cutting Machine Laminated glass cutting machine
- Category: >>>
- Supplier: Anhui Ruilong Glass Machinery Co. Ltd.
Share on (60704337272):
Product Overview
Description
Buyer also purchase those
Product Description
This machine was research and development in our company. IT`s easy to use ,highly adaptab.
Structure of machine
Frame was made with international square steel tube and box iron by welding.The key position had been annealing treatment and
gantry milling. So the frame has high stability and strength.
Two-part construction to assemble the machine. The first part is the artificial auxiliary feeding and transmission part, equipped
with automated positioning system. The second paragraph contains the upper and lower knife cutting system, the cutting film
system, the heating system, and the auxiliary discharge system
Machine Parameters
1.Size of machine:4800*3800*1300mm
2.Weight:about 3000KG
3.Processing range of glass size:400*400mm --- 3700*2500mm
4.Processing range of glass thickness:3+X+3mm---8+X+8mm
5.Cutting speed: cutting twice in one minute
6.Temperature and time of heating: Adjust by operater
7.Pressure of pushing and breaking: Adjust by operater
Machine configuration
1.Motor:Delta SERVO MOTOR
2.Drive: Delta
3.Plc and touch screen: Delta
4.Electrical elements: CHINT
5.Program: Self-Design
6.Heatting tube: China
7.Timing belts and wheels: China
8.Air cylinder and knife: Self-Design
9. Knife wheels: imported from Japan
10.Draught fan: China
11.Transmission shaft: China
12.Felt:imported
13.Proportional control valve: SMC from Japan
Technical process
Man-machine interface HMI setting system parameters such as glass width, length, under knife pressure, etc.一一mechanical placement
of glass into the synchronous belt area of the cutting table一一Automatic transmission and positioning of glass according to the cut
size of input（There's a location system）一一Knife head at zero一一Pneumatic lower knife, upper and lower knife wheel cut（There's an
automatic injection system）一一Cut and lift一一The upper press starts the press, and the lower surface glass breaks open一一Under the
top rod up the glass, the upper surface of the glass break open一一Heat bar, start heating一一The vacuum suction cup absorbs the glass
on both sides of the tangent line and pulls the cutting seam apart一一Cutting film（PVB or EVA）一一The cutting action is complete and
the entire artifact is transferred to the next segment tangent position（If you need to turn around and cut, you need to do it
manually）一一Whole cutting is complete.一一Manually move the processed glass to the lower slide flip bracket with the air float
assembly.
Advantage
1. Can automatically set the cutting length width, labor saving.
2. Compare the previous ones,faster, more accurate.
Structure of machine
Frame was made with international square steel tube and box iron by welding.The key position had been annealing treatment and
gantry milling. So the frame has high stability and strength.
Two-part construction to assemble the machine. The first part is the artificial auxiliary feeding and transmission part, equipped
with automated positioning system. The second paragraph contains the upper and lower knife cutting system, the cutting film
system, the heating system, and the auxiliary discharge system
Machine Parameters
1.Size of machine:4800*3800*1300mm
2.Weight:about 3000KG
3.Processing range of glass size:400*400mm --- 3700*2500mm
4.Processing range of glass thickness:3+X+3mm---8+X+8mm
5.Cutting speed: cutting twice in one minute
6.Temperature and time of heating: Adjust by operater
7.Pressure of pushing and breaking: Adjust by operater
Machine configuration
1.Motor:Delta SERVO MOTOR
2.Drive: Delta
3.Plc and touch screen: Delta
4.Electrical elements: CHINT
5.Program: Self-Design
6.Heatting tube: China
7.Timing belts and wheels: China
8.Air cylinder and knife: Self-Design
9. Knife wheels: imported from Japan
10.Draught fan: China
11.Transmission shaft: China
12.Felt:imported
13.Proportional control valve: SMC from Japan
Technical process
Man-machine interface HMI setting system parameters such as glass width, length, under knife pressure, etc.一一mechanical placement
of glass into the synchronous belt area of the cutting table一一Automatic transmission and positioning of glass according to the cut
size of input（There's a location system）一一Knife head at zero一一Pneumatic lower knife, upper and lower knife wheel cut（There's an
automatic injection system）一一Cut and lift一一The upper press starts the press, and the lower surface glass breaks open一一Under the
top rod up the glass, the upper surface of the glass break open一一Heat bar, start heating一一The vacuum suction cup absorbs the glass
on both sides of the tangent line and pulls the cutting seam apart一一Cutting film（PVB or EVA）一一The cutting action is complete and
the entire artifact is transferred to the next segment tangent position（If you need to turn around and cut, you need to do it
manually）一一Whole cutting is complete.一一Manually move the processed glass to the lower slide flip bracket with the air float
assembly.
Advantage
1. Can automatically set the cutting length width, labor saving.
2. Compare the previous ones,faster, more accurate.
Specification
item | value |
Applicable Industries | Manufacturing Plant |
After Warranty Service | Video technical support, Online support, Spare parts, Field maintenance and repair service |
Local Service Location | None |
Showroom Location | None |
Condition | New |
Machine Type | Glass Cutting Machine |
Production Capacity | 1/1 (piece/min) |
Place of Origin | China |
Anhui | |
Brand Name | Ruilong |
Voltage | 380V/50HZ |
Power | 15-22KW |
Dimension(L*W*H) | 3500*2200*1200 |
Weight | 1800kg |
Certification | Main component with CE |
Warranty | 1 Year |
Key Selling Points | Easy to Operate |
Glass Thickness | 3+...+3___6+....+6mm |
Machinery Test Report | Provided |
Video outgoing-inspection | Provided |
Marketing Type | Ordinary Product |
Warranty of core components | 1 Year |
Core Components | Motor, PLC |
After-sales Service Provided | Engineers available to service machinery overseas |
Motor | Japan Yaskawa |
Screw rails | HIWIN |
Cutter wheel/ wheel clip | NIKKEN |
Control card | America, Galil |
Power | 15KW |
Cutting precision | ≤±1.5mm/m |
Maximum cutting size | 3800*2600mm |
Minimum cutting size | 150mm |
Name | laminated glass cnc automatic glass cut machine |
