Станок для резки гранита с ЧПУ

Product Overview

Description

GBSJ-1500 CNC Wire Saw Machine

Features:

1.     The degree of automation is high. The electrical system adopts the CNC technician; the main running adopts the stable, good quality and strong servo motor. The running of the wheel adopts the stepping motor.

2.     The structure is reasonable, the running is stable. The main frame is gantry type. And because the up/down of the two flywheels adopt the roller type structure, the up/down action is light and flexible, stable. The wire wheel is through balance adjustment so its work is more stable. The up/down is controlled by separate stepping motors, so it is easy for adjustment and easy to keep in the same height.

3.     The operation is easy. It adopts the man-machine menu which is easy for reading and monitoring. Design the shape on the computer and then copy it to this system. It will change it into the procedure directly.

4.     The tension of the wire adopts hydraulic system. This hydraulic system is designed with the hydraulic accumulator and discharge pressure switch which can make sure the stable pressure and is easy for maintance.

5.     It is major in profiling processing of the granite and marble, can cutting different sizes of arc slab, solid columns and hollow columns and large-scale stone line, letter etc.



Technical data:

Name	Unit	GBSJ-1500	GBSJ-1800
Saw diameter	mm	Φ8-Φ10	¢8-¢10
Saw gross length	mm	17300	19300
Line speed	m/s	0-35	0-35
Lifting travel of cutter	mm	1600	1900
Max process size	mm	3500X2000X1500	3600*2000*1800
Production efficiency	m2/h	1-2 (marble) 0.5-1 (granite)	1-2(marble) 0.5-1(granite)
Full size	mm	8200×6000×3800	8800×6800×4800
Main motor	kw	11	11
Gross power	kw	19.38	19.38
Gross weight	kg	7000	9000
Worktable whether revolve		no	no
Worktable size	mm	1350*2000	1800*2000
Guide wheel diameter	mm	200	200



Guarantee & after sale service:
1) Warranty for half year. Extra fee is paid if out of date. Any damage to the machine caused by improper use will be charged.
2) when receiving the 30% down payment, we will prepare machine for you, it will take 2-5 weeks, to get the shipping pictures for you.
3) 24-hour technical support Internet or by Telephone, free instructions and Problem solving.

FAQ:
1, How to pay to you?
T/T in advance We accept 30% deposit, 70% before shipment
2, How long is the delivery time?
For standard machines, it would be 2-5 weeks; For non-standard machines and customized machines according to client s specific requirements, it would be 10 days longer.
3, Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
4, How about the documents after shipment?
After shipment, we will send all original documents to you by DHL or Tele-Release, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
5, What is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package
Save space as much as possible for container loading.
