Hot Sale High Quality PTFE Tubing Fep tubing/ PTFE TUBE

Product Overview

Description

Hot Sale High Quality Teflon PTFE Tubing/

Teflon PTFE tube/ PTFE Tube







Product Specification:



PTFE Tube (Perfluoroalkoxy) offers excellent crack and stress resistance and is used when more demanding mechanical characteristics are required. PTFE Tubing is the product of choice for applications involving extreme chemical resistance combined with high temperature exposure.  PTFE Tubing is preferred when additional clarity, flexibility, and a higher continuous service temperature are required. PTFE Tubing provides stiffness and long flex-life (up to 500º F) and has all the general properties of PTFE.

In the semiconductor and pharmaceutical industries, PTFE TUBE (High Purity) Tubing is used for fluid handling applications requiring an extremely low level of chemical extractables.



Feature & Benefits:



1,Higher thermal stability than FEP
2,Working temperature of up to 500º F (260º C)
3,Non-flammable
4,Lower permeability than FEP
5,Combines attributes of PTFE and FEP
6,Translucent
7,Maintains mechanical strength at high temperatures
8,Moisture absorption close to zero
9,Superior high purity properties
10,Availabe in coiled hose and convoluted constructions
11,FDA compliant for food contact
12,Suitable for use with flare or conventional fittings





PFA Teflon Tubing Applications:

Aerospace &Transportation Technology, Electronics, Components & Insulators, Chemical & Pharmaceutical Manufacturing, Food Processing, Environmental Sciences, Air Sampling, Fluid Transfer Devices and Water Processing Systems



Product dimension:



O.D.	I.D.	O.D./I.D.	O.D.	I.D.	O.D./I.D.	Working	Burst	Minimum
(mm)	(mm)	Tolerance (mm)	(in)	(in)	Tolerance (in)	Pressure* PSIG(bar)	Pressure+ PSIG(bar)	Bend  Radius(in)
4	2	+/- 0.11	0.157	0.078	+/- 0.004	480 (33)	2400 (166)	1/2
5	3	+/- 0.11	0.197	0.118	+/- 0.004	376 (26)	1882 (130)	1/2
6	4	+/- 0.13	0.236	0.157	+/- 0.005	308 (21)	1538 (106)	1/2
7	5	+/- 0.13	0.276	0.197	+/- 0.005	259 (18)	1297 (89)	1-3/4
8	6	+/- 0.13	0.315	0.236	+/- 0.005	224 (15)	1120 (77)	1-3/4
9	7	+/- 0.13	0.354	0.276	+/- 0.005	197 (14)	985 (68)	2-1/2
10	8	+/- 0.13	0.393	0.315	+/- 0.005	176 (12)	878 (60)	2-1/2
12	10	+/- 0.15	0.472	0.393	+/- 0.006	144 (9.9)	721 (50)	3-1/2
14	12	+/- 0.15	0.551	0.472	+/- 0.006	122 (8.4)	612 (42)	4
16	14	+/- 0.15	0.63	0.551	+/- 0.006	106 (7.3)	531 (37 )	5-1/2
