3mm 4mm 5mmT heat resistant ceramic fireplace glass robax glass /round glass fireplace
- Category: >>>
- Supplier: Xinyu Xu Tking Glass Co. ltd.
Share on (60706820795):
Product Overview
Description
l The scope of application:
a) Indoor heating/The windows panel heaters
b) Cover glass heating radiator
c) Reflecting cupand High performance pan light lamp cover
d) Infrared dryer cover
e) Projector protection cover
f) UV shield
g) Barbecue machine panel
l Thickness and size:
Thickness(mm) | size(mm) | |
3.0 | 1954´1100 | 1580´890 |
4.0 | 1954´1100 | 1580´890 |
5.0 | 1954´1100 | 1580´890 |
l Physical properties:
Density ρ | approx. 2.6 g / cm3 |
Modulus of elasticity E | approx. 93 x 103 MPa |
Bending strength σbB | approx. 35 MPa |
l Thermal Properties:
Coefficient of Linear Thermal Expansion α(20 - 700°C) | (0 ± 0.5) x 10-6 /K |
Specific Thermal Capacity (CP20 - 100°C) | 0.8x103J/(kg x k) |
Specific Thermal Conductivity λ(90°C) | 1.6W/(m x k) |
Resistance to Thermal Gradients(RTD) | Tes, max1) ≤ 700°C |
Resistance to Thermal Shock | Tes, max ≤ 700°C |
Working temperature | 760°C |
l Chemical properties:
Acid resistance DIN 12116 | The lowest grade S3 |
Alkali resistance ISO 695 | The lowest grade A2 |
Water resistance DIN ISO 719 | HGB 1 |
