Wholesale 10% 20% Transparent Solar Panel Cadmium Telluride Thin Film BIPV
- Category: >>>
- Supplier: Xiamen Solar First Energy Technology Co. Ltd.
Share on (60706876191):
Product Overview
Description
Photovoltaic 20% Transparent Garden Frameless Crystal Roof Sheet Solar Panel Unit
| Electrical Specifications | Specification | |||
| Nomina power(Pm) | SF-ST1-48 | SF-ST1-64 | SF-ST1-72 | |
| Open Circuit Voltage(Voc) | 48w | 64W | 72w | |
| Short Circuit Current(Isc) | 116V | 116V | 116V | |
| Voltage at Max,Power(Vm) | 0.59A | 0.78A | 0.88A | |
| Current at Max.Power(Im) | 0.55A | 0.73A | 0.82A | |
| Transparency | 40% | 20% | 10% | |
| Systen Properties(at STC) | Maximum System Voltag | 1000(600UL) | ||
| Limiting Reverse Current | 2 | |||
| Maximum Series Fuse | 2 | |||
| Temperature Coefficients(at STC) | Temperature Coefficients of Isc | α=0.060%/℃ | ||
| Temperature Coefficients of Voc | β=0.321%/℃ | |||
| Temperature Coefficients of Pm | γ=0.214%/℃ | |||
| Mechanical Specifications | Size | 1200mm*600mm*6.8mm | ||
| Area | 0.72m² | |||
| Weight | 11.8Kg | |||
| Frame | None | |||
| Lead Cable | 2.5mm² 650mm | |||
| Connectors | MC4 | |||
| Bypass Diode | 10A | |||
| Cell Type | Cadmium Telluride(CdTe) | |||
| Cover Type | 3.2mm+0.76EVA/PVB/UV reduction | |||
| Encapsulation | EVA//PVB | |||
