New Colorimeter SC10 for Color Testing with Competitive Price
- Category: >>>
- Supplier: Sino Age Development Technology
Share on (60706959656):
Product Overview
Description
New Colorimeter SC10 for Color Testing with Competitive Price
Introduction
SC80 precise colorimeter is mainly applied to plastic, painting, design, plating, costume, printing and dyeing industries.. It can do the color analysis and color controlling. SC10 is the economic version that is designed for the assembly line. It could meet almost all the test requirements for the customers and
its high accuracy is also suitable for other color testing work.
Key Features
\u008F\u008F The 2.4" color ful screen and por table design make you feel comfor table.
\u008F\u008F Suitable for internal, external color evaluation and data control.
\u008F\u008F High precision measurement, stable per formance.
\u008F\u008F PC sof tware for data management.
\u008F\u008F National measurement accreditation.
\u008F\u008F USB data transmit
\u008F\u008F Yellow, whiteness measurement (only for SC80)
Specifications
| Model | SC80 | SC10 |
| Accuracy | Standard deviation within ΔE*ab*, 0.08 (average value of 30 times @ the standard white tabula) | Standard deviation within ΔE*ab*, 0.1 (average value of 30 times @ the standard white tabula) |
| Measuring range | L*: 1-100 | |
| Illuminating system | 8/d (8o diffuse illumination), specular component included (SCI) | |
| Light source | LED | |
| Measuring conditions | CIE 10° standard observer; CIE D65 light source | |
| Measuring time | about 0.5 seconds | |
| Rectification | White board rectification/Black board rectification | |
| Storage | 100 samples and 100 data groups for each sample | 10 samples and 100 data groups for each sample |
| Display | Colorimetric values: L*a*b*, L*c*h*, ΔE*ab, XYZ, relative RGB values Color difference values: Δ(L*a*b), Δ(L*C*h) Whiteness values: hunter whiteness, ganz whiteness Yellowness value: YI | Colorimetric values: L*a*b*, L*c*h*, ΔE*ab, XYZ, relative RGB values Color difference values: Δ(L*a*b), Δ(L*C*h) |
| Communication interface | USB2.0, printer(optional) | |
| Aperture (mm) | Ø8 | |
| Power supply | 4 pcs of AA alkaline batteries / nickel batteries / DC 5V adaptor | |
| Weight (g) | 550g | |
| Dimension (mm) | 77x86x210 | |
Standard package
SC80/SC10 main unit 1
Standard white tabula 1
Standard black cavity 1
USB cable 1
Software CD 1
Power adapter 1
Operation manual 1
Bag(SC80 only) 1
