80 blades Stone Cutter and Gang Saw Machine for marble
- Category: >>>
- Supplier: Xiamen Great Base Co. Ltd.
Share on (60708633563):
Product Overview
Description
Features:
1.ARTICULATED RECTILINEAR GUIDES
Movement of blade holder frame on articulated guides. This system reduces to a minimum problem of the blade holder frame. It greatly reduces maintenance costs because it does not require replacement like the traditional sideways, this articulated rectilinear guides is easy maintenance and less cost.
2. Equal Distribution of Mechanical Thrust Over all Machine Component
♦All the energy and mechanical thrust towards the blade holder is spread on two connecting rods and two cranks instead of just one.
♦The two connecting rods which are attached to the extremes of the blade holder help the articulated guides to ensure that it is movement remains perfectly rectilinear without any deviation. This is especially important when there are more blades on one side of the frame ( the machine applies greater pressure where there are more blades), and when the blocks are of different heights (because initially more pressure would be applied on the higher block).
3. THE ROTATING LEAD NUTS
which worm screws of the Block trolley platform are situated above the columns and Lubricated Automatically.
4. BATTERY UNIT
Details of the battery unit. The battery supports have been designed to allow easy maintenance and facilitate the replacement of the roller bearings without having to break the cement foundations. The flywheel weights 8 tons and has a diameter of 3300mm
5. LIFT SYSTERM
The lifting system with inverter of the block trolley platform.
6. Motor
The motor with hydraulic converter can saving the electric, and more safe to the machine.
Technical Data:
Name | Unit | GB-80/S800 |
Max. block size | mm | 3200(L)×2000(W)×2000(H) |
Main motor power | kw | 110 |
Dimensions | mm | 11900 (L)×5060(W)×4960(H) |
Auxiliary motor power | kw | 11 |
Speed | cm/hours | 8-32 |
Stroke of the blades | mm | 800 |
Size of Blades | mm | 4400×180 |
Water consumption | L/min/blade | 10 |
Installed No. of blade | pieces | 80 |
Total weight | tons | 55 |
Guarantee & after sale service:
1) Warranty for half year. Extra fee is paid if out of date. Any damage to the machine caused by improper use will be charged.
2) when receiving the 30% down payment, we will prepare machine for you, it will take 2-5 weeks, to get the shipping pictures for you.
3) 24-hour technical support Internet or by Telephone, free instructions and Problem solving.
FAQ:
1, How to pay to you?
T/T in advance We accept 30% deposit, 70% before shipment
2, How long is the delivery time?
For standard machines, it would be 2-5 weeks; For non-standard machines and customized machines according to client s specific requirements, it would be 10 days longer.
3, Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you.
4, How about the documents after shipment?
After shipment, we will send all original documents to you by DHL or Tele-Release, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
5, What is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package
Save space as much as possible for container loading.
