High brightness outdoor waterproof smd full color p10 led display module outdoor
- Category: >>>
- Supplier: Shenzhen Longcheng Photoelectric Technology Co. Ltd.
Share on (60709158494):
Product Overview
Description
Product Description
High brightness outdoor waterproof smd full color p10 led display module outdoor
Features
1.ultra thin and ultra light
2.low attenuation,High brightness,high gray level,good stability,anti-static
3.entire die casting aluminum
4. waterproof IP65
Application:
1,LED video wall, conference replacing projectors, wedding backdrop, stage background, parties
2,Hotel, disco, bars, night club ceiling and floor decoration
3,Architectures exterior lighting decoration
| P10 outdoor full color led display IP65 | ||
| Unit Module | Item | Parameter |
| Part No | P10-LC-4S | |
| Pixel pitch | 10mm | |
| Module size | 320mm*160mm | |
| Tube chip color | full color | |
| Pixel Density | 10000dots/sqm | |
| led type | SMD3535 | |
| led combination | 1R1G1B | |
| Module resolution | 32*16dots | |
| main technical parameters | Scan method | 1/4s |
| refresh rate | ≥1920Hz-3840Hz | |
| Brightness of white balance | ≥5500-10000cd/sqm | |
| cabinet resolution | 960*96dots | |
| cabinet size | 960mm*960mm | |
| Best view distance | 10m-80m | |
| Best view angle | 160°(W)*160°(H) | |
| Storage temperature | -35℃-+85℃ | |
| Working temperature | -20℃-+50℃ | |
| working voltage | AC110/220V±10% | |
| Average power consumption | <400W/sqm | |
| Max power consumption | <800W/sqm | |
| brightness adjustment method | Brightness induction automatic adjustment | |
| MTBF | ≥5000hrs | |
| Control system | Display card | DVI graphics |
| Control method | Synchronization | |
| Operation syetem | WIN98,WINXP,WIN2000,etc | |
| display sign | RF,S-Video,RGB,RGBHV,YUV, YC,COMPOSITION, etc | |
Company Information
Production process
Certification
Our service
Pre-sale service:
1. Inquiries will be replied within 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offered.
5. Other requireed services such as special packing design, factory visiting and so on.
In-sale service:
1. Tracking producing procedures all the time.
2. Provide photos and videos as per customer's requirement during production.
3. Free spare parts provided.
After-sale service:
1. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
2. Warranty: 2years
3. Free technician training.
4. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
