Non invasive Sphygmomanometer Calibrator

Product Overview

Description

Description:

ME02 is used for simulating human body blood pressure with output signal stability and good repeatability. It
provides static pressure output & measuring, automatic leaking testing,dynamic blood pressure simulating
function .that is used for calibrating sphygomanometer in metrology body,hospital,the University lab,
Sphygmomanometer manufacturers and so on .



Features

Portable,easy to use in field
With rechargeable battery
Automatically pressurized and depressurized
7 inch touch-screen, external wireless mouse
Adopt import pressure transducer and pressure
components
Remindering when the pressure value
approaching
Stability time set 0-60s selectable
Voice is less than 40 decibel
Build in adults/newborn cuff
18 group application, only set once time for
permanent store
Dimensions:300L×250W×110H (mm)
Weight:4kg



Specifications

Generated pressure:(0-60)kPa /(0-450mmHg)
Control pressure stability:0.05%F.S
Pressure measuring:(0-60)kPa/(0-450)mmHg
Accuracy:±0.1%F.S
Resolution:0.01kPa(0.1mmHg)
Adults simulating range:
Systolic pressure (50-255)mmHg/(6.7-34)kPa
Diastolic pressure (30-195)mmHg/(4.0-26)kPa
Newborn simulating range:
Systolic pressure (30-120)mmHg/(4.0-16)kPa
Diastolic pressure (10-100)mmHg/(1.3-13.3)kPa
Blood pressure value repeatability:
less than(2mmHg)
Heart rate range:(30-250) times/mins
Heart rate accuracy:±1%R.D
Pulse value:(0.1-2.4)ml
