medical radiography devices digital radiology system x ray machine C arm x ray detector
medical radiography devices digital radiology system x-ray machine C arm x ray detector

medical radiography devices digital radiology system x ray machine C arm x ray detector

Share on (60709787633):


Price:RUB 2,047,086.00 - RUB 2,081,204.10

Quantity:


Product Overview

Description

Product Description

Kenid DRX U50 Radiology System UC-ARM Type

1. High quality image and direct radiography function system.

2. Use imaging detector and DR image processing software,no need x-ray film,can print out .

3. Realize remote consultation and save a large number of medical records.

Technology parameter

NO
Technical Parameters
X-ray generator
Supply voltage:Three-phase380V±38V
Maximum output power:30kw
Operating frequency≥100kHz
Photography tube voltage:Can continuous ,Adjust the step length of 1 kv, the adjusting range is 40 kv ~ 150 kv
Photography tube current:Can step adjustment, adjustment range,10mA~200mA
Load time:adjustable range,2ms~6300ms
Current-time:Can step adjustment, adjustment range,0.1mAs~500mAs
Operating console
DC12V
X-ray tube
Maximum working voltage: 125kv
Bi-focus:0.6mm(small focal point)/1.2mm(big focal point)
Anode input power:15KW(small focal point);30KW(big focal point)
The anode optical Angle:12°
The anode rotation speed:3000rpm
Anode heat content:150KHU
Flat panel detector
Fluorescent material: Direct growth cesium iodide
Scanning the area size:17×17inch
Spatial resolution:≥3.0 lp/mm
Analog-digital conversion:16bit
SLC
Pixel region:431.8 × 431.8 mm2
Pixels array:2816 × 2816
Pixel size:154μm
Image read time:1~1.5s
Time of exposure:Shortest:1 ms; longest:10 s

Main configuration

High Frequency High Voltage Generator
YJG30R-A
1 set
Operating Console
YJO-
1 set
X-ray Tube
H1083
1 set
Beam Limiting Device
M-38
1 set
Flat Panel Detector
1800R
1 set
SLC
YJT-Ⅰ
1 set
DR Rack
YJDR-Ⅰ
1 set
Mobile Photography Bed
YJS-Ⅲ
1 set
Acquisition Workstation (Computer)
Color Screen
1 set
GRID
103line
1 set
High Voltage Cable
75kV
1 pair
Detailed Images
Packing & Delivery

Our Digital x-ray Equipment can be sent to our customers by sea,air or international Express.

And we will recommend the best shipping type for our cusomters according to their actual needs.

Our Certificates
Our Company

Each year,Kenid team will attend more than 10 international medical fairs both in domestic and overseas.We believe that “ no pains,no gains”.We are not just selling products,but also trying our best to offer our customers superior service .
