DVB Finder Hellobox B1 Blueteeth Satfinder Mini Satellite Finder

Product Overview

Description

DVB Finder Hellobox B1 blueteeth Satfinder mini satellite finder



Highlight
Please use it as below steps:
1. Search "DVBFinder" in Google Play Store or scan QR code on the package to install the Android APK.
2. Connect Hellobox B1 with Power bank, Open DVBFinder to create Blueteeth connection
3. Select the satellite, transponder, then start moving the antana
---Multi standard demodulation & decoding
---DVB-S2 CCM
QPSK+1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
8PSK+3/5, 2/3, 3/4, 5/6, 8/9, 9/10
16APSK+2/3, 3/4, 4/5, 5/6, 8/9, 9/10
32APSK+3/4, 4/5, 5/6, 8/9, 9/10
---Legacy DVB-S,QPSK+1/2, 2/3, 3/4, 5/6, 7/8
---VCM mode supported
---Dummy frame insertion supported
---Automatic standard recognition
---Support 1 to 60Mbaud symbol rates
---Fast channel blind scan for RF frequency & symbol rate acquisition
---Minimized software overhead
---High performance equalizer, canceling echo introduced by front end
---Simple AGC – Tuner interface
---Build in DC cancellers to remove DC component
---IQ imbalance compensator
---Automatic roll-off factor (0.35/0.25/0.20) detection
---Automatic spectrum inversion
---Signal quality and statistic, allowing improved monitoring and debug
---Programmable parallel/serial data output interface.
---DiSEqCTM v2.2 modulation output for full control of LNB and satellite antenna
