DDGT 350KV Generator ndt XXG 3505 X ray flaw detector Pipeline Welding Inspection Equipment Ceramic X ray Tube
DDGT 350KV Generator ndt XXG-3505 X-ray flaw detector Pipeline Welding Inspection Equipment Ceramic X-ray Tube
DDGT 350KV Generator ndt XXG-3505 X-ray flaw detector Pipeline Welding Inspection Equipment Ceramic X-ray Tube
DDGT 350KV Generator ndt XXG-3505 X-ray flaw detector Pipeline Welding Inspection Equipment Ceramic X-ray Tube
DDGT 350KV Generator ndt XXG-3505 X-ray flaw detector Pipeline Welding Inspection Equipment Ceramic X-ray Tube
DDGT 350KV Generator ndt XXG-3505 X-ray flaw detector Pipeline Welding Inspection Equipment Ceramic X-ray Tube
DDGT 350KV Generator ndt XXG-3505 X-ray flaw detector Pipeline Welding Inspection Equipment Ceramic X-ray Tube

DDGT 350KV Generator ndt XXG 3505 X ray flaw detector Pipeline Welding Inspection Equipment Ceramic X ray Tube

Share on (60710475656):


Price:$9,300.00 - $9,500.00

Quantity:


Product Overview

Description



Our Company




Product Description


Product Application

Portable X-ray Flaw Detector are widely used in the defense industry, boiler, pressure vessel, shipbuilding, papermaking, petrochemical, aerospace and industrial machinery and etc, it is the most ideal equipment for nondestructive testing.


Specifications For  XXG -3505X Ray Flaw Detector
Power supply
AC 198-242V/ 50-60 Hz
Output Voltage
200-350KV
Power Capacity
3.5 KW
2Output Current
5mA
Fluctuation
±2%
Focal Spot Size (mm)
2.5*2.5
Radiation Coverage
40°
Max Penetration (Fe)
60mm
Sensitivity
1.8%
Size of Controller (mm)
320*180*350
Weight of controller (kg)
13
Size of generator (mm)
320*320*660
Weight of generator (kg)
41
Cooling
Air
Cooling
Air
Insulation
SF6
Working Pressure
0.34-0.45 Mpa
Working Temp& Humidity
-30-40 ℃, ≤85%




Main Features

1) Factory with 30 years' experience

2) Multi Protection Functions

3) Smaller size, light weight

4) CE marked, ISO Certified







Certifications




Our Service


Pre-Sales Service

* Inquiry and consulting support.

* Free Training

* View our Factory.

After-Sales Service

*24 hours online service

* one year warranty



Packing & Delivery


Packaging
Size
450*450*880mm
Weight
80 Kg



Packaging Details
The normal package is wooden bof export to european countries,the wooden box will be fumigated.


Packaging
Size
450*450*880mm
Weight
95 kg



Packaging Details
Customized Suitcase, easy for carry.
