SF 758 The newest waterproof moisture proof touch screen digital temperature controller for electric steamer
- Category: >>>
- Supplier: Zhongshan Shangfang Instrument Meter Co. Ltd.
Share on (60710946431):
Product Overview
Description
SF-758 The newest waterproof moisture proof touch screen digital temperature controller for electric steamer
Product Description
Specification
1 Suitable for electric steam cabinet control
2 Temperature, time display
3 Pre-heat control, heat preservation function
4 Automatic constant temperature
5 Countdown timer range:1~180min
6 Factory default:30minutes
7 Temperature preservation temperature range:0~100°C Accuracy:+-1 °C
8 Four mode pre-store fast select function
Electric heating tube1 relay:30A/250VAC
Electric heating tube 2 relay:10A/250VAC
Electric heating tube 3 relay:10A/250VAC
9 Defrost:10A/250VAC
10 Evap. fan:5A/250VAC
11 Dimension:208*64*72.5mm
12 Mounting hole dimension:191.5*57mm
Parameters
| Code | Function | Set range | Default |
| E1 | Start temp. Countdown | 00~100°C | 00°C |
| E2 | Energy saving pre-heat time | 00~30min | 15min |
| E3 | Holding temp. hysteresis | 01~20°C | 05°C |
| E4 | Holding temp. Start delay time | 00~10min | 2min |
| E5 | Offset on room temp | -30~30°C | 00°C |
| P1 | Alarm Temperature | 70~150°C | 120°C |
| P2 | Water resistance alarm value | 05~100kΩ | 55kΩ |
