10kw Large Power BOPP Plastic Film Blowing Machine Corona Treater

Product Overview

Description

HW3010 Large Power Corona Treater for Plastic Film Blowing Machine



Main Characteristics:

 1.It adopts power switching IGBT module,and is high reliability.

     2.It tracks and locks the operating frequency automatically.

     3.It has the function of low load start,whichi can eliminate the interference to the power supply               and electronic equipment.

     4.It has kinds of protections such as phase absence protections,phase error protections,over               voltage protection and short circuit protection.

     5.It has protections function for the rubber roller stop-running and electrode opening.

Technical Specification:

Item	HW3010
Power supply	AC380V±10%/-15%
Mains frequency	50 Hz ± 5 %
Line speed	120-180m/min
Output frequency	15-40Khz
Max.output power	10.0 Kw
Corona output	a. Constant at same speed b. No influence of supply voltage
Dynes level	38-48Dynes/cm
Treated side	Singel side or Double side
The max treated width	2000mm
Treated material	PP,PE,PS etc plastic film,Metal film
Packing size(Wooden case)	70*72*180CM   100KG(Generator)                                                                                              55*55*60CM     80KG(High voltage transformer)
Environment temperature	-10°C ~ +40°C
Environment humidity	20%~93% no condensation
Application	Film blowing machine,printing machine ,laminating machine etc
Corona treatment station	Avalible as customer's requirements

Benifits:



   1.Easy to install



   2.Accurate output power



   3.Small, compact and economical design



   4.Low maintenance



   5.User friendly



   6.Maximum operator saftey



 Optional value added features:



   1.Pneumatic operated treater station.



   2.Zero speed switch to protect silicoan sleeve.



   3.Ozone extraction system efficiently remove ozone and cool the electrode.



   4.Steel corona station frame with painting anti-rust.



 Please contact us for more machine technical datails and proposal.

 We can send you machine video for clear understanding.
