XK7125 China CNC milling machine price with CE
- Category: >>>
- Supplier: WMT CNC Industrial Co. Ltd.
Share on (60713679011):
Product Overview
Description
Product Description
Specification | XK7125 |
Worktable size(LxW) | 900x230mm |
T-slot (NxWx D) | 3/14/65mm |
X axis travel | 500mm |
Y axis travel | 280mm |
Z axis travel | 350mm |
Distance from spindle nose to worktable surface | 50-400mm |
Distance from spindle center to column | 340mm |
Rapid feed speed(X/Y/Z) | 8/8/6m/min |
Spindle taper | BT30 |
Spindle speed range | 20-6000rpm |
Main motor power | 2.2kw |
AC servo motor torque(X/Y/Z) | 4/4/6N.m |
Over size(LxWxH) | 1900x1450x2150mm |
Net weight | 1500kgs |
Detailed Images
